AD9959BCPZ

Direct Digital Synthesis

AD9959BCPZ Description

The AD9959BCPZ, manufactured by Analog Devices Inc., is a high-performance Direct Digital Synthesis (DDS) integrated circuit. It is designed for applications requiring high-frequency, high-resolution, and low-phase noise signal generation. The device is surface-mounted and operates within a supply voltage range of 1.71V to 1.96V. It is compliant with the RoHS3 directive and is unaffected by REACH regulations.

AD9959BCPZ Features

• Technical Specifications: The AD9959BCPZ boasts a 10-bit resolution, providing a high level of precision in signal generation. It features a 32-bit tuning word width, enabling precise control over the generated frequencies. The device has a master fclk of 500 MHz, allowing for high-speed signal generation.

• Performance Benefits: The AD9959BCPZ offers low phase noise and high spectral purity, making it ideal for applications where signal integrity is critical. Its high-resolution capabilities allow for fine control over frequency and amplitude, enabling precise signal generation.

• Unique Features and Advantages: The device's 500 MHz master fclk and 10-bit resolution set it apart from similar models, offering superior performance in high-frequency applications. Its low phase noise and high spectral purity make it an excellent choice for applications requiring high signal quality.

• Package and Mounting: The AD9959BCPZ is available in a 56LFCSP package and is surface-mounted, making it suitable for a wide range of applications and easy to integrate into existing systems.

AD9959BCPZ Applications

The AD9959BCPZ is ideal for a variety of applications, including:

• Communications: Its high-frequency capabilities and low phase noise make it well-suited for use in communication systems, such as radio frequency (RF) transceivers and signal generators.

• Test and Measurement: The device's precision and stability make it an excellent choice for use in test and measurement equipment, such as signal analyzers and spectrum analyzers.

• Radar and Navigation: The AD9959BCPZ's high-resolution and low phase noise make it ideal for use in radar and navigation systems, where precise signal generation is critical.

Conclusion of AD9959BCPZ

The AD9959BCPZ is a high-performance Direct Digital Synthesis integrated circuit from Analog Devices Inc. Its combination of high resolution, low phase noise, and high spectral purity make it an excellent choice for a wide range of applications, including communications, test and measurement, and radar and navigation. Its unique features and advantages set it apart from similar models, making it a top choice for demanding applications where signal quality and precision are critical.

AD9959BCPZ Documents

Download datasheets and manufacturer documentation for AD9959BCPZ

PCN Assembly/Origin :

Mult Changes 09/Jun/2021

Datasheets :

AD9959

Design Resources :

Phase Coherent FSK Modulator (CN0186)
