Analog Devices Inc.

ADL5601ARKZ-R7

RF Amplifiers

ADL5601ARKZ-R7 Description

The ADL5601ARKZ-R7 is a high-performance, general-purpose RF amplifier designed and manufactured by Analog Devices Inc. This device operates within a frequency range of 50MHz to 4GHz, making it suitable for a wide range of applications. With a gain of 15dB and a P1dB of 19dBm, it delivers excellent performance in terms of signal amplification and linearity. The noise figure is 3.7dB, ensuring minimal signal degradation. The device is designed for surface mount applications and is compliant with RoHS3 regulations.

ADL5601ARKZ-R7 Features

• Frequency Range: 50MHz to 4GHz, covering a broad spectrum for versatile applications.
• Gain: 15dB, providing significant signal amplification.
• P1dB: 19dBm, ensuring linear operation and minimal distortion.
• Noise Figure: 3.7dB, preserving signal integrity.
• Supply Voltage: 4.5V to 5.5V, offering flexibility in power supply design.
• Current Consumption: 83mA, suitable for energy-efficient systems.
• Mounting Type: Surface Mount, ideal for compact and dense PCB layouts.
• RoHS Compliance: ROHS3 Compliant, adhering to environmental regulations.
• REACH Status: REACH Unaffected, ensuring compliance with European chemical regulations.
• Moisture Sensitivity Level (MSL): 1 (Unlimited), indicating no special precautions are needed for moisture exposure.

ADL5601ARKZ-R7 Applications

The ADL5601ARKZ-R7 is ideal for applications requiring high-frequency signal amplification with minimal distortion and noise. Specific use cases include:

• GPS Systems: Amplifying weak GPS signals for improved reception and accuracy.
• Communication Systems: Enhancing signal strength in radio and cellular communication systems.
• Test and Measurement Equipment: Providing stable amplification for accurate signal analysis and testing.
• Radar Systems: Ensuring reliable signal transmission and reception in radar applications.

Conclusion of ADL5601ARKZ-R7

The ADL5601ARKZ-R7 stands out due to its broad frequency range, high gain, and low noise figure, making it a versatile choice for various high-frequency applications. Its RoHS3 compliance and REACH unaffected status also make it an environmentally responsible option. With its performance benefits and unique features, the ADL5601ARKZ-R7 is an excellent choice for applications requiring reliable and efficient signal amplification.
