Analog Devices Inc.

ADSP-21565KSWZ8

DSP

ADSP-21565KSWZ8 Description

The ADSP-21565KSWZ8 is a high-performance digital signal processor (DSP) from Analog Devices Inc., designed for demanding applications that require advanced signal processing capabilities. This device is part of the SHARC® series, known for their exceptional computational power and versatility. The ADSP-21565KSWZ8 operates at a clock rate of 800MHz, providing ample processing speed for complex algorithms. It is equipped with 1.625MB of on-chip RAM, enabling efficient data handling without the need for external memory in many applications. The device is also designed to operate within a wide temperature range of 0°C to 70°C, making it suitable for both indoor and outdoor environments.

ADSP-21565KSWZ8 Features

• Clock Rate: 800MHz, ensuring rapid processing of complex algorithms.
• Memory: 1.625MB of on-chip RAM for efficient data management.
• Operating Temperature: 0°C to 70°C, suitable for a variety of environments.
• Voltage: Core at 1.00V and I/O at 3.30V, ensuring stable operation.
• Non-Volatile Memory: OTP (896B) for storing critical data.
• Interface: Supports DDR3, DDR3L, I2C, Link Port, QSPI, SPDIF, SPI, SPORT, UART/USART, providing flexibility in connectivity.
• Mounting Type: Surface Mount, facilitating integration into various systems.
• Package: Tray, suitable for bulk handling and automated assembly.
• RoHS Compliance: ROHS3 Compliant, adhering to environmental standards.
• ECCN: 5A992C, indicating export control classification.
• REACH Status: REACH Unaffected, ensuring compliance with European chemical regulations.
• MSL: 3 (168 Hours), indicating the moisture sensitivity level.

ADSP-21565KSWZ8 Applications

The ADSP-21565KSWZ8 is ideal for applications that demand high computational power and fast data processing. It is particularly suited for:

• Audio Processing: Utilizing its high clock rate and on-chip RAM for real-time audio signal processing.
• Telecommunications: For baseband processing in wireless communication systems, taking advantage of its wide temperature range and robust interfaces.
• Automotive Systems: In infotainment and advanced driver-assistance systems (ADAS), where reliability and performance are critical.
• Industrial Automation: For control systems requiring real-time processing and high-speed data handling.

Conclusion of ADSP-21565KSWZ8

The ADSP-21565KSWZ8 stands out in the DSP market due to its combination of high clock rate, ample on-chip memory, and a wide range of interfaces. Its robust design, compliance with environmental standards, and wide operating temperature range make it a versatile choice for a variety of high-performance applications. Whether in audio processing, telecommunications, automotive, or industrial automation, the ADSP-21565KSWZ8 delivers the performance and reliability needed for cutting-edge electronic systems.

ADSP-21565KSWZ8 Documents

Download datasheets and manufacturer documentation for ADSP-21565KSWZ8

PCN Assembly/Origin :

ADSP-2156y Bond REV 08/Jan/2024

Datasheets :

ADSP-21562-63, 65-67, 69
