HMC190BMS8ETR

RF Switches

HMC190BMS8ETR Description

The HMC190BMS8ETR is a high-performance RF switch designed and manufactured by Analog Devices Inc., a leading company in the electronics industry. This SPDT (Single Pole Double Throw) switch operates within a frequency range of 0Hz to 3GHz, making it suitable for a wide range of applications. With a compact 8MSOP package, the HMC190BMS8ETR offers excellent performance in a small form factor.

HMC190BMS8ETR Features

• Frequency Range: 0Hz to 3GHz, providing versatility for various applications
• Voltage Supply: 3V to 8V, ensuring compatibility with different power sources
• REACH Status: REACH Unaffected, indicating compliance with European regulations
• Test Frequency: 2.5GHz, demonstrating reliable performance at high frequencies
• P1dB: 29dBm, offering high power handling capability
• IIP3: 55dBm, ensuring excellent linearity and signal integrity
• Insertion Loss: 0.8dB, minimizing signal degradation
• Isolation: 30dB, providing effective signal separation
• RoHS Status: ROHS3 Compliant, adhering to environmental standards
• Moisture Sensitivity Level (MSL): 1 (Unlimited), suitable for use in various environments
• Circuit: SPDT, offering single-pole double-throw switching functionality
• Mounting Type: Surface Mount, facilitating easy integration into PCB designs
• Impedance: 50Ohm, maintaining consistent signal transmission
• Package: Tape & Reel (TR)

HMC190BMS8ETR Applications

The HMC190BMS8ETR is ideal for various applications where high-frequency signal switching is required. Some specific use cases include:

1. Communication Systems: The switch's wide frequency range and low insertion loss make it suitable for use in communication systems, such as cellular base stations and satellite communication equipment.
2. Test and Measurement Equipment: The HMC190BMS8ETR's high P1dB and IIP3 values ensure reliable performance in test and measurement applications, where signal integrity is crucial.
3. Military and Aerospace: The switch's REACH compliance and moisture sensitivity level make it suitable for use in military and aerospace applications, where environmental factors can impact performance.
4. Automotive Radar: The HMC190BMS8ETR's high-frequency capabilities and compact package size make it an excellent choice for automotive radar systems, where space and performance are critical.

Conclusion of HMC190BMS8ETR

The HMC190BMS8ETR from Analog Devices Inc. is a versatile and high-performance RF switch that offers a wide frequency range, low insertion loss, and excellent isolation. Its compact 8MSOP package, REACH compliance, and RoHS3 status make it an ideal choice for a variety of applications, including communication systems, test and measurement equipment, military and aerospace, and automotive radar. With its unique features and advantages over similar models, the HMC190BMS8ETR is a reliable and efficient solution for high-frequency signal switching needs.
