HMC558ALC3BTR

RF Mixers

HMC558ALC3BTR Description

The HMC558ALC3BTR is a high-performance, monolithic double-balanced mixer designed for use in RF and microwave communication systems. Manufactured by Analog Devices Inc., this IC is part of the RF Mixers category and offers a range of technical specifications and performance benefits that make it ideal for various applications.

HMC558ALC3BTR Features

• Frequency Range: The HMC558ALC3BTR operates within a frequency range of 5.5GHz to 14GHz, making it suitable for a wide range of communication systems.
• Noise Figure: With a low noise figure of 8.5dB, this mixer provides excellent signal-to-noise performance, ensuring high-quality signal processing.
• Number of Mixers: This device features a single mixer, simplifying the design and reducing complexity in RF systems.
• Mounting Type: The HMC558ALC3BTR is designed for surface mount, allowing for easy integration into PCB designs and enabling compact, efficient layouts.
• Package: The device is available in a Tape & Reel (TR) package, facilitating automated assembly and reducing production costs.
• RoHS Compliance: The HMC558ALC3BTR is compliant with RoHS3 standards, ensuring environmental responsibility and regulatory compliance.
• Moisture Sensitivity Level (MSL): With an MSL of 3 (168 Hours), this mixer is designed to withstand exposure to moisture, making it suitable for a variety of environmental conditions.

HMC558ALC3BTR Applications

The HMC558ALC3BTR is ideal for use in a variety of RF and microwave communication systems, including:

• Satellite Communications: The wide frequency range and low noise figure make this mixer suitable for satellite communication systems, where signal quality is critical.
• Radar Systems: The HMC558ALC3BTR's performance characteristics are well-suited for radar systems, where high-frequency signals and low noise figures are essential.
• Wireless Communication Systems: This mixer is ideal for wireless communication systems, such as cellular networks, where high performance and reliability are required.

Conclusion of HMC558ALC3BTR

The HMC558ALC3BTR from Analog Devices Inc. is a high-performance, monolithic double-balanced mixer that offers a range of technical specifications and performance benefits. Its wide frequency range, low noise figure, and RoHS compliance make it an ideal choice for a variety of RF and microwave communication systems. With its unique features and advantages over similar models, the HMC558ALC3BTR is a reliable and efficient solution for demanding applications in the electronics industry.
