MAX77960BEFV06+

MAX77960BEFV06+ Description

The MAX77960BEFV06+ is a high-performance, 25VIN, 6AOUT USB-C Power Delivery (PD) Buck-Boost regulator designed for a wide range of applications including converters, USB devices, and digital cameras. Manufactured by Analog Devices Inc./Maxim Integrated, this regulator is part of the Special Purpose Regulators category and is known for its robust performance and versatility.

This regulator supports a broad input voltage range of 3.5V to 25.4V, making it suitable for various power sources. It delivers a stable output voltage between 8V and 13.05V, ensuring reliable power delivery to connected devices. The MAX77960BEFV06+ is housed in a surface-mount package, which is ideal for compact and space-constrained designs. It is available in a tray package, facilitating easy handling and integration into manufacturing processes.

The product is currently in an active status, indicating its availability and suitability for new designs. It is also compliant with the REACH and RoHS3 standards, ensuring it meets the highest environmental and safety regulations. The Moisture Sensitivity Level (MSL) is rated at 1 (Unlimited), making it highly resistant to moisture and suitable for a wide range of environmental conditions.

MAX77960BEFV06+ Features

The MAX77960BEFV06+ offers several unique features that set it apart from similar models:

• Wide Input Voltage Range: The regulator supports an input voltage range of 3.5V to 25.4V, providing flexibility and compatibility with various power sources.
• High Output Current: It delivers up to 6A of output current, ensuring sufficient power for demanding applications.
• USB-C Power Delivery: The regulator is designed to support USB-C Power Delivery, enabling fast and efficient charging and data transfer.
• Buck-Boost Topology: This topology allows the regulator to efficiently convert voltage levels, making it suitable for both step-up and step-down applications.
• Surface-Mount Technology: The surface-mount package ensures a compact design, ideal for modern electronics where space is a premium.
• Compliance and Safety: The MAX77960BEFV06+ is REACH Unaffected and ROHS3 Compliant, ensuring it meets stringent environmental and safety standards.
• Moisture Resistance: With an MSL rating of 1 (Unlimited), the regulator is highly resistant to moisture, enhancing its reliability in various environments.

MAX77960BEFV06+ Applications

The MAX77960BEFV06+ is ideal for a variety of applications due to its versatile design and high performance:

• Converters: The wide input and output voltage ranges make it suitable for power conversion applications, ensuring efficient power delivery.
• USB Devices: The support for USB-C Power Delivery makes it an excellent choice for USB-powered devices, providing fast charging and reliable power management.
• Digital Cameras: The regulator's ability to deliver high current and stable voltage ensures reliable power supply for digital cameras, enhancing their performance and battery life.

Conclusion of MAX77960BEFV06+

The MAX77960BEFV06+ is a versatile and high-performance regulator designed to meet the demands of modern electronics. Its wide input voltage range, high output current, and support for USB-C Power Delivery make it an ideal choice for a variety of applications. The regulator's compliance with environmental and safety standards, along with its moisture resistance, ensures reliability and longevity in various conditions. Whether used in converters, USB devices, or digital cameras, the MAX77960BEFV06+ offers superior performance and efficiency, making it a standout choice in the Special Purpose Regulators category.
