GigaDevice

GD25Q128ESIGR

GD25Q128ESIGR Description

The GD25Q128ESIGR is a high-performance, 128Mbit SPI/QUAD flash memory IC manufactured by GigaDevice Semiconductor (HK) Limited. This memory IC is designed to offer robust and reliable storage solutions for a wide range of applications. It features a memory organization of 16M x 8 bits, providing a substantial storage capacity in a compact 8-SOP package. The GD25Q128ESIGR operates within a voltage range of 2.7V to 3.6V and supports a clock frequency of up to 133 MHz, ensuring fast data transfer rates and efficient performance.

GD25Q128ESIGR Features

• High-Speed Operation: With a clock frequency of up to 133 MHz, the GD25Q128ESIGR delivers rapid data access and transfer capabilities, making it suitable for applications requiring high-speed memory solutions.
• Low Access Time: The IC boasts an access time of 7 ns, which significantly enhances the overall system performance by reducing the time required to read data from the memory.
• Efficient Write Cycle Times: The GD25Q128ESIGR offers write cycle times of 70µs for a word and 2.4ms for a page, ensuring efficient data writing operations.
• Wide Voltage Range: The memory IC operates within a voltage range of 2.7V to 3.6V, providing flexibility in power supply requirements and compatibility with various systems.
• Surface Mount Technology: The GD25Q128ESIGR is available in a surface mount package, making it ideal for automated assembly processes and compact designs.
• Compliance and Reliability: The IC is REACH unaffected and RoHS3 compliant, ensuring it meets environmental and safety standards. Additionally, it has a moisture sensitivity level (MSL) of 3 (168 hours), making it suitable for various manufacturing environments.
• Memory Format and Organization: The GD25Q128ESIGR features a FLASH memory format with a 16M x 8 memory organization, providing a large storage capacity in a small form factor.

GD25Q128ESIGR Applications

The GD25Q128ESIGR is ideal for a variety of applications due to its high-speed performance, low access time, and efficient write cycle times. Some specific use cases include:

• Consumer Electronics: Ideal for devices such as smartphones, tablets, and digital cameras where fast data access and storage are crucial.
• Industrial Systems: Suitable for industrial control systems, automation equipment, and IoT devices that require reliable and high-speed memory solutions.
• Automotive Applications: The GD25Q128ESIGR can be used in automotive infotainment systems, advanced driver-assistance systems (ADAS), and other automotive electronics where robust memory performance is essential.
• Telecommunications: The IC is well-suited for communication devices and infrastructure, such as routers, switches, and base stations, where high-speed data transfer and storage are required.

Conclusion of GD25Q128ESIGR

The GD25Q128ESIGR is a versatile and high-performance SPI/QUAD flash memory IC that offers significant advantages over similar models. Its combination of high-speed operation, low access time, efficient write cycle times, and wide voltage range make it an excellent choice for a wide range of applications. The GD25Q128ESIGR's compliance with environmental and safety standards further enhances its reliability and suitability for various industries. Whether used in consumer electronics, industrial systems, automotive applications, or telecommunications, the GD25Q128ESIGR provides a reliable and efficient memory solution that meets the demands of modern electronic devices.
