MCP4022T-502E/CH

Digital Potentiometers

MCP4022T-502E/CH Description

The MCP4022T-502E/CH is a digital potentiometer from Microchip Technology, designed to provide precise control and adjustment in various electronic applications. This device features a 5kOhm resistance, 64-tap rheostat configuration, and a linear taper. It operates within a supply voltage range of 2.7V to 5.5V and offers a temperature coefficient of 150ppm/°C. With a typical resistance-wiper value of 70 Ohms and a tolerance of ±20%, this potentiometer ensures reliable performance across a wide range of applications.

MCP4022T-502E/CH Features

• Series: WiperLock™
• Configuration: Rheostat
• Number of Taps: 64
• Number of Circuits: 1
• Temperature Coefficient (Typ): 150ppm/°C
• Voltage - Supply: 2.7V ~ 5.5V
• Resistance (Ohms): 5k
• Tolerance: ±20%
• Resistance - Wiper (Ohms) (Typ): 70
• Taper: Linear
• Interface: Up/Down (U/D, CS)
• Mounting Type: Surface Mount
• Package: Tape & Reel (TR)
• RoHS Status: ROHS3 Compliant
• Moisture Sensitivity Level (MSL): 1 (Unlimited)
• ECCN: EAR99
• HTSUS: 8542.39.0001

MCP4022T-502E/CH Applications

The MCP4022T-502E/CH is ideal for applications requiring precise resistance adjustment, such as:

1. Audio Volume Control: Its linear taper and 64-tap configuration make it suitable for adjusting audio volume levels in various devices.
2. Sensor Calibration: The MCP4022T-502E/CH can be used to calibrate sensors by adjusting their resistance values.
3. Industrial Control Systems: This digital potentiometer can be employed in industrial control systems to fine-tune control parameters.
4. Medical Equipment: Its precise resistance adjustment capabilities make it suitable for use in medical equipment that requires accurate control.

Conclusion of MCP4022T-502E/CH

The MCP4022T-502E/CH digital potentiometer from Microchip Technology offers a reliable and precise solution for applications requiring adjustable resistance. Its 64-tap rheostat configuration, linear taper, and ±20% tolerance ensure accurate and consistent performance. With its RoHS3 compliance and moisture sensitivity level of 1, this potentiometer is suitable for a wide range of applications in various industries. Its unique features and advantages make it an ideal choice for applications requiring precise control and adjustment.
