Microchip Technology

MCP6241-E/P

OP Amps, Buffer Amps ICs

MCP6241-E/P Description

The MCP6241-E/P from Microchip Technology is a general-purpose operational amplifier (op-amp) designed for low-power, precision applications. Packaged in an 8-pin DIP (Through Hole), this single-channel op-amp operates over a wide supply voltage range of 1.8V to 5.5V, making it suitable for battery-powered and portable devices. With an ultra-low input bias current of 1 pA, it minimizes errors in high-impedance sensor interfaces. The device offers a gain bandwidth product (GBWP) of 550 kHz and a slew rate of 0.3V/µs, ensuring stable performance in signal conditioning and filtering applications. Its low quiescent current (50µA) enhances energy efficiency, while ROHS3 compliance and REACH unaffected status ensure environmental and regulatory compatibility.

MCP6241-E/P Features

• Low Power Consumption: Only 50µA supply current extends battery life in portable applications.
• Wide Voltage Range: Operates from 1.8V to 5.5V, supporting both 3.3V and 5V systems.
• High Input Impedance: 1 pA input bias current reduces signal distortion in high-Z circuits.
• Moderate Speed: 550 kHz GBWP and 0.3V/µs slew rate balance power and performance.
• Robust Output Drive: 23 mA output current enables direct driving of small loads.
• Reliable Packaging: 8-pin DIP (Through Hole) for easy prototyping and robust assembly.
• Environmental Compliance: ROHS3 Compliant and REACH Unaffected for global use.

MCP6241-E/P Applications

• Sensor Signal Conditioning: Ideal for amplifying low-level signals from pH sensors, thermocouples, and strain gauges due to its low input bias current.
• Battery-Powered Systems: Suited for wearables, IoT nodes, and medical devices where power efficiency is critical.
• Active Filters & Integrators: The 550 kHz GBWP supports low-to-moderate bandwidth filtering.
• Portable Instrumentation: Used in handheld meters, data loggers, and other field-deployable tools.
• Consumer Electronics: Enhances signal integrity in audio preamps, touch interfaces, and low-power comparators.

Conclusion of MCP6241-E/P

The MCP6241-E/P is a versatile, low-power op-amp that excels in precision analog designs requiring wide voltage operation, minimal power draw, and high input impedance. Its balance of performance and efficiency makes it a preferred choice for sensor interfaces, portable electronics, and energy-sensitive systems. With Microchip’s reliability and compliance with environmental standards, this op-amp is a robust solution for both prototyping and production.

MCP6241-E/P Documents

Download datasheets and manufacturer documentation for MCP6241-E/P

PCN Assembly/Origin :

Qualification Revision 18/Dec/2013

Datasheets :

Analog and Interface Product Guide       MCP6241_42_44

PCN Packaging :

Packing Changes 10/Oct/2016       Label and Packing Changes 23/Sep/2015

Manuals :

Development Tools Catalog

Design Resources :

MCP6241 Development Tool Selector

HTML Datasheet :

MCP6241_42_44

Environmental Information :

Microchip CA Prop65       Microchip RoHS       Microchip REACH
