PIC16F15243-I/P

Microcontrollers

Microchip Technology's PIC16F15243-I/P is a microcontroller (MCU) that belongs to the PIC16F series. It is a mid-range device with enhanced functionality and performance, making it suitable for a wide range of applications.

Description:

The PIC16F15243-I/P is a 28-pin microcontroller that features a 14-bit wide instruction word and a rich instruction set. It is based on the enhanced mid-range core (enhanced XR) architecture, which provides high code density and execution speed. The device operates at a frequency of up to 20 MIPS, making it suitable for applications that require fast processing.

Features:

Some of the key features of the PIC16F15243-I/P include:

1. Enhanced mid-range core (enhanced XR) architecture
2. 14-bit wide instruction word
3. 28-pin package
4. Up to 20 MIPS performance
5. 8 KB of Flash program memory
6. 256 bytes of RAM
7. 256 bytes of EEPROM memory
8. 16-bit wide data memory
9. 8-channel, 10-bit ADC
10. Two 16-bit timer/counters with capture/compare/PWM functions
11. USART for serial communication
12. SPI and I2C interfaces for communication with external devices
13. On-chip debugging and programming support

Applications:

The PIC16F15243-I/P is suitable for a wide range of applications, including:

1. Industrial control systems
2. Medical devices
3. Consumer electronics
4. Automotive systems
5. Smart home applications
6. IoT devices
7. Data acquisition and signal processing systems
8. Motor control applications
9. Battery management systems
10. Security systems

In summary, the PIC16F15243-I/P is a powerful and versatile microcontroller that offers high performance and a wide range of features. It is suitable for a variety of applications that require fast processing, advanced control, and communication capabilities.

PIC16F15243-I/P Documents

Download datasheets and manufacturer documentation for PIC16F15243-I/P

Errata :

PIC16F15213/14/23/24/43/44 Errata

Datasheets :

PIC16F15213/14/23/24/43/44

PCN Design/Specification :

PIC16F15213/14/23/24/43/44 16/Jun/2022       PIC16F15213/14/23/24/43/44 10/May/2022

Environmental Information :

Microchip CA Prop65       Microchip RoHS       Microchip REACH
