SY100EL91ZC

Translators, Level Shifters

SY100EL91ZC Description

The SY100EL91ZC is a high-performance, unidirectional translator IC designed by Microchip Technology. This logic IC chip is part of the 100EL series and is specifically engineered to provide reliable signal translation between different logic levels. The SY100EL91ZC features a PECL input signal and an ECL output signal, making it ideal for applications requiring differential signaling. With a robust operating temperature range of 0°C to 85°C (TA), this IC is suitable for a wide range of industrial and commercial environments.

The SY100EL91ZC is housed in a surface-mount package, ensuring ease of integration into modern circuit designs. It is available in bulk packaging, which is convenient for large-scale production and assembly processes. The device comprises three channels per circuit, each capable of unidirectional signal translation, providing efficient and reliable performance. The moisture sensitivity level (MSL) is rated at 1 (Unlimited), making it highly resilient to environmental moisture, thus enhancing its reliability and longevity.

SY100EL91ZC Features

• Input Signal Compatibility: The SY100EL91ZC supports PECL input signals, ensuring compatibility with high-speed digital systems.
• Differential Output: The ECL output type facilitates differential signaling, which is crucial for reducing noise and improving signal integrity.
• Wide Operating Temperature Range: With an operating temperature range of 0°C to 85°C (TA), the SY100EL91ZC is well-suited for various environmental conditions.
• Surface-Mount Technology: The surface-mount package type allows for efficient and compact integration into modern PCB designs.
• Unidirectional Channels: The three unidirectional channels per circuit provide dedicated signal paths, enhancing performance and reducing crosstalk.
• Bulk Packaging: Available in bulk packaging, the SY100EL91ZC is ideal for large-scale manufacturing and assembly processes.
• Moisture Sensitivity Level 1: The MSL rating of 1 (Unlimited) ensures the device is highly resistant to moisture, enhancing its reliability and longevity.
• Compliance and Safety: The SY100EL91ZC is REACH unaffected and classified under ECCN EAR99 and HTSUS 8542.39.0001, ensuring compliance with international regulations.

SY100EL91ZC Applications

The SY100EL91ZC is ideal for a variety of applications where high-speed, reliable signal translation is required. Some specific use cases include:

• Telecommunications: In high-speed data transmission systems, the SY100EL91ZC can be used to translate signals between different logic levels, ensuring accurate and efficient communication.
• Networking Equipment: For networking devices that require differential signaling, the SY100EL91ZC provides a reliable solution for signal translation.
• Industrial Control Systems: The wide operating temperature range and moisture resistance make the SY100EL91ZC suitable for industrial environments where harsh conditions are common.
• Consumer Electronics: In consumer electronics, the SY100EL91ZC can be used to translate signals between various components, ensuring high-speed and reliable performance.

Conclusion of SY100EL91ZC

The SY100EL91ZC from Microchip Technology is a versatile and reliable unidirectional translator IC designed for high-speed signal translation. Its unique features, such as PECL input, ECL output and, differential signaling, make it stand out from similar models. The wide operating temperature range, surface-mount package, and moisture resistance further enhance its suitability for a variety of applications. Whether used in telecommunications, networking, industrial control systems, or consumer electronics, the SY100EL91ZC provides a robust and efficient solution for signal translation needs.
