VSC3316YYP

Analog Switches - Special Purpose ICs

VSC3316YYP Description

The VSC3316YYP from Microchip Technology is a high-performance 16×16 crosspoint switch IC designed for demanding signal routing applications. This surface-mount device operates on a 2.5V single supply, making it suitable for low-power systems. It features advanced signal equalization, ensuring robust signal integrity in high-speed data transmission environments. With a 16:16 multiplexer/demultiplexer circuit, it provides flexible routing for complex backplane, telecommunications, and video systems. The device is RoHS3 compliant and adheres to REACH Unaffected standards, meeting stringent environmental regulations. Packaged in a tray, it has a Moisture Sensitivity Level (MSL) of 4 (72 hours), requiring careful handling during assembly.

VSC3316YYP Features

• 16-channel crosspoint switch for high-density signal routing.
• Advanced signal equalization mitigates signal degradation in long traces or high-frequency applications.
• Low-voltage operation (2.5V) reduces power consumption in energy-sensitive designs.
• Surface-mount (SMT) packaging enables compact PCB integration.
• RoHS3 and REACH Unaffected compliance ensures environmental and regulatory compatibility.
• 72-hour MSL4 rating for moisture-sensitive applications.
• Backplane and telecom optimized with robust performance in noisy environments.

VSC3316YYP Applications

• Backplane routing: Ideal for high-speed data communication in server and storage systems.
• Telecommunications: Supports signal switching in base stations and network infrastructure.
• Video distribution: Enables seamless routing in broadcast and professional AV systems.
• Test and measurement equipment: Facilitates flexible signal path configuration in lab environments.
• Data center interconnects: Ensures reliable signal integrity in high-bandwidth applications.

Conclusion of VSC3316YYP

The VSC3316YYP stands out as a versatile and reliable 16×16 crosspoint switch, combining low-power operation, advanced signal conditioning, and high channel density. Its robust design makes it ideal for backplane, telecom, and video systems, where signal integrity and flexibility are critical. With Microchip Technology's quality assurance and compliance with RoHS3/REACH, this IC is a top choice for engineers designing next-generation high-speed signal routing solutions.

VSC3316YYP Documents

Download datasheets and manufacturer documentation for VSC3316YYP

PCN Assembly/Origin :

VSCyyy 05/Nov/2020

Datasheets :

VSC3316 Product Brief

PCN Packaging :

VSCYYY 09/Jan/2017       Label and Packing 01/Oct/2018

PCN Design/Specification :

Marking Changes 27/Sep/2018

Environmental Information :

Microchip CA Prop65       Microchip RoHS       Microchip REACH
