Monolithic Power Systems

MA702GQ-Z

Angle, Linear Position Measuring

MA702GQ-Z Description

The MA702GQ-Z is a Hall Effect sensor designed and manufactured by Monolithic Power Systems Inc., a leading provider of power solutions for the electronics industry. This sensor is specifically engineered for angle and linear position measuring applications, offering a range of technical specifications and performance benefits that make it ideal for various use cases. With an active product status and compliance to the REACH and RoHS3 standards, the MA702GQ-Z ensures reliable performance and environmental sustainability.

MA702GQ-Z Features

• Technology: Hall Effect
• Voltage - Supply: 3.3V
• Output: PWM (Pulse Width Modulation)
• REACH Status: REACH Unaffected
• RoHS Status: ROHS3 Compliant
• Moisture Sensitivity Level (MSL): 1 (Unlimited)
• Termination Style: SMD (SMT) Tab
• Actuator Type: External Magnet, Not Included
• For Measuring: Angle
• Output Signal: Programmable
• Package: Tape & Reel (TR)

The MA702GQ-Z stands out from similar models due to its programmable output signal, which allows for greater flexibility in application design. Its external magnet actuator type enables precise measurement of angle and linear position, while the SMD (SMT) Tab termination style ensures easy integration into surface mount applications.

MA702GQ-Z Applications

The MA702GQ-Z is ideal for a variety of applications where accurate angle and linear position measurement is crucial. Some specific use cases include:

1. Automotive: For measuring steering angle, throttle position, and other critical parameters in modern vehicles.
2. Industrial Automation: In robotics and machinery for precise control of movement and positioning.
3. Aerospace: For monitoring the position of flaps, rudders, and other critical components in aircraft.
4. Consumer Electronics: In devices such as gaming controllers and VR headsets for accurate motion tracking.

Conclusion of MA702GQ-Z

In conclusion, the MA702GQ-Z is a versatile and reliable Hall Effect sensor that offers a range of technical specifications and performance benefits. Its programmable output signal, external magnet actuator type, and SMD (SMT) Tab termination style make it an ideal choice for a variety of applications in the automotive, industrial automation, aerospace, and consumer electronics industries. With its active product status and compliance to REACH and RoHS3 standards, the MA702GQ-Z is a dependable solution for accurate angle and linear position measurement.

MA702GQ-Z Documents

Download datasheets and manufacturer documentation for MA702GQ-Z

Datasheets :

MA702

Environmental Information :

MonolithicPower Systems Environmental Compliance Declaration
