Monolithic Power Systems

MP1907GQ-Z

Gate Drivers ICs

MP1907GQ-Z Description

The MP1907GQ-Z is a high-performance gate driver IC from Monolithic Power Systems, designed for driving half-bridge configurations in power electronics applications. It offers a wide supply voltage range of 4.5V to 18V, making it suitable for a variety of power management systems. With an independent channel type and a high-side voltage of up to 100V, this IC provides robust performance in demanding environments. The MP1907GQ-Z is RoHS3 compliant, REACH unaffected, and EAR99 classified, ensuring compliance with global environmental and trade regulations.

MP1907GQ-Z Features

• Voltage - Supply: 4.5V to 18V for versatile power management
• Rise/Fall Time (Typ): 12ns/9ns for fast switching capabilities
• High Side Voltage - Max (Bootstrap): 100V for robust high-side driving
• Logic Voltage - VIL, VIH: 1V/2.4V for reliable logic level compatibility
• Number of Drivers: 2 for driving half-bridge configurations
• Mounting Type: Surface Mount for compact integration
• Current - Peak Output (Source, Sink): 2.5A/2.5A for efficient current handling
• Moisture Sensitivity Level (MSL): 1 (Unlimited) for enhanced reliability in humid conditions

MP1907GQ-Z Applications

The MP1907GQ-Z is ideal for a range of power electronics applications, including:

• Motor Control: For driving brushless DC motors in industrial and automotive applications
• Power Conversion: In high-efficiency power supplies and converters
• Renewable Energy: For driving solar inverters and wind turbine converters
• Battery Management: In battery chargers and management systems for electric vehicles

Conclusion of MP1907GQ-Z

The MP1907GQ-Z from Monolithic Power Systems is a versatile and robust gate driver IC, offering a combination of high performance, wide supply voltage range, and compliance with global regulations. Its unique features, such as fast switching times and high-side voltage capability, make it an excellent choice for demanding power electronics applications. With its reliable performance and compact surface-mount design, the MP1907GQ-Z is a valuable addition to any power management system.

MP1907GQ-Z Documents

Download datasheets and manufacturer documentation for MP1907GQ-Z

Datasheets :

MP1907 Datasheet

HTML Datasheet :

MP1907 Datasheet

Environmental Information :

MonolithicPower Systems Environmental Compliance Declaration
