Monolithic Power Systems

MP20075DH-LF-Z

Special Purpose Regulators

MP20075DH-LF-Z Description

The MP20075DH-LF-Z is a high-performance, single-output voltage regulator designed by Monolithic Power Systems Inc., specifically tailored for applications in the converter and DDR domains. This surface-mount device operates within a wide input voltage range of 1.05V to 3.6V and provides a stable 3.3V output. With a compact 8MSOP package, it is ideal for space-constrained designs. The MP20075DH-LF-Z is REACH unaffected, RoHS3 compliant, and classified under EAR99, making it suitable for international trade.

MP20075DH-LF-Z Features

• Voltage Regulation: Delivers a precise 3.3V output voltage, ensuring consistent performance across various operating conditions.
• Input Voltage Range: Capable of accepting inputs from 1.05V to 3.6V, providing flexibility in power source selection.
• Mounting Type: Surface Mount, facilitating integration into densely packed electronic systems.
• Package: 8MSOP, a small form factor that conserves space on the PCB.
• Moisture Sensitivity Level (MSL): Rated at level 2, indicating a one-year shelf life under controlled conditions.
• ECCN and RoHS Compliance: EAR99 and RoHS3 compliant, respectively, ensuring regulatory adherence and environmental responsibility.

MP20075DH-LF-Z Applications

The MP20075DH-LF-Z is particularly well-suited for applications where stable and efficient voltage regulation is critical:

• Converters: Ideal for voltage conversion in power supply units, ensuring reliable power delivery to sensitive electronics.
• DDR Modules: Provides stable power to DDR memory modules, enhancing the performance and reliability of computing systems.
• Embedded Systems: Its compact size and low power consumption make it suitable for embedded systems where space and energy efficiency are paramount.

Conclusion of MP20075DH-LF-Z

The MP20075DH-LF-Z stands out for its versatility in voltage regulation, wide input voltage range, and compact form factor. Its unique combination of features makes it an excellent choice for applications requiring stable power delivery in a small footprint. With its adherence to international trade regulations and environmental standards, the MP20075DH-LF-Z is a reliable and responsible choice for designers looking to enhance the performance and reliability of their electronic systems.

MP20075DH-LF-Z Documents

Download datasheets and manufacturer documentation for MP20075DH-LF-Z

Datasheets :

MP20075 Datasheet

HTML Datasheet :

MP20075 Datasheet

Environmental Information :

MonolithicPower Systems Environmental Compliance Declaration
