Monolithic Power Systems

MP2562DS-LF-Z

DC Switching Voltage Regulators

MP2562DS-LF-Z Description

The MP2562DS-LF-Z is a high-performance, adjustable output voltage DC switching voltage regulator from Monolithic Power Systems Inc., designed to meet the demands of modern electronic devices. With an input voltage range of 4.5V to 50V and an output voltage adjustable from 0.8V to 47V, this regulator is capable of delivering up to 1A of continuous output current. Its synchronous rectifier feature ensures high efficiency, while the buck topology and surface mount design make it suitable for a wide range of applications.

MP2562DS-LF-Z Features

• Adjustable Output Voltage: The MP2562DS-LF-Z offers an adjustable output voltage range of 0.8V to 47V, providing flexibility in power supply design.
• High Input Voltage Range: With an input voltage range of 4.5V to 50V, this regulator can handle a wide range of input voltages, making it suitable for various power sources.
• 1A Output Current: The MP2562DS-LF-Z can deliver up to 1A of continuous output current, making it suitable for applications requiring high current output.
• High Switching Frequency: The regulator operates at a switching frequency of up to 4MHz, allowing for compact design and high efficiency.
• Synchronous Rectifier: The synchronous rectifier feature ensures high efficiency and low power loss.
• Buck Topology: The buck topology provides high efficiency and fast transient response.
• Surface Mount: The surface mount design allows for compact and efficient PCB layout.
• REACH Unaffected and RoHS3 Compliant: The MP2562DS-LF-Z meets the latest environmental regulations, making it suitable for green electronics.

MP2562DS-LF-Z Applications

The MP2562DS-LF-Z is ideal for a variety of applications where high efficiency, adjustable output voltage, and high input voltage range are required. Some specific use cases include:

1. Portable Electronics: Due to its high efficiency and compact size, the MP2562DS-LF-Z is suitable for powering portable electronic devices such as smartphones, tablets, and wearable devices.
2. Industrial Equipment: The wide input voltage range and adjustable output voltage make it suitable for industrial equipment that requires a stable power supply.
3. Telecommunications: The high efficiency and high input voltage range make the MP2562DS-LF-Z suitable for powering telecommunications equipment that requires a stable and reliable power supply.

Conclusion of MP2562DS-LF-Z

The MP2562DS-LF-Z from Monolithic Power Systems Inc. is a versatile and high-performance DC switching voltage regulator that offers adjustable output voltage, high input voltage range, and high efficiency. Its unique features, such as synchronous rectifier and buck topology, make it an ideal choice for a wide range of applications, including portable electronics, industrial equipment, and telecommunications. With its adherence to environmental regulations, the MP2562DS-LF-Z is a reliable and eco-friendly solution for your power supply needs.

MP2562DS-LF-Z Documents

Download datasheets and manufacturer documentation for MP2562DS-LF-Z

Datasheets :

MP2562 Datasheet

HTML Datasheet :

MP2562 Datasheet

Environmental Information :

MonolithicPower Systems Environmental Compliance Declaration
