NXP Semiconductors

OM11043,598

Embedded, MCU, DSP Evaluation Boards

OM11043,598 Description

The OM11043,598 is an mbed-enabled evaluation board from NXP Semiconductors, designed for rapid prototyping and development of embedded systems. Centered around the LPC1768 microcontroller (part of the LPC1700 series), this board offers a robust platform for engineers working with ARM Cortex-M3-based designs. Packaged as a complete kit with board(s) and cable(s), it simplifies setup and accelerates time-to-market. The board complies with ROHS3 and REACH environmental standards, ensuring global usability. Its fixed mounting type and evaluation platform design make it ideal for lab and field testing, while its ECCN 3A991A2 classification confirms its suitability for export-controlled applications.

OM11043,598 Features

• High-Performance MCU: Utilizes the LPC1768 (Cortex-M3, 100 MHz) with integrated peripherals like USB, CAN, and Ethernet.
• mbed Ecosystem: Pre-integrated with mbed OS, enabling cloud-based development, RTOS support, and extensive library access.
• Plug-and-Play Design: Includes essential cables and interfaces (USB, JTAG) for immediate use.
• Industrial Compliance: ROHS3 and REACH Unaffected status ensures adherence to stringent environmental regulations.
• Flexible Connectivity: Features 10/100 Ethernet, USB Host/Device, and multiple GPIOs for diverse interfacing needs.
• Robust Packaging: Housed in a protective box with MSL Not Applicable, ensuring durability during storage and shipping.

OM11043,598 Applications

• IoT Prototyping: Ideal for connected devices due to built-in Ethernet and mbed cloud compatibility.
• Industrial Automation: Supports CAN and real-time control for motor drives and PLCs.
• Consumer Electronics: Enables rapid development of USB-enabled gadgets (HID, mass storage).
• Education and Research: Perfect for teaching ARM architecture and embedded systems design.
• Embedded Labs: Used for firmware validation and peripheral testing in pre-production stages.

Conclusion of OM11043,598

The OM11043,598 stands out as a versatile, compliance-ready evaluation board for LPC1768-based designs. Its integration with the mbed platform reduces development overhead, while its industrial-grade features (Ethernet, CAN, USB) cater to demanding applications. Whether for IoT, industrial control, or education, this board delivers a balanced mix of performance, ease of use, and regulatory compliance, making it a superior choice over generic development kits.

OM11043,598 Documents

Download datasheets and manufacturer documentation for OM11043,598

Datasheets :

LPC1763-69 Datasheet       OM11043

PCN Packaging :

All Dev Label Update 15/Dec/2020

HTML Datasheet :

OM11043

Environmental Information :

NXP USA Inc REACH       NXP USA Inc RoHS Cert
