NC7SP04P5X

Gates and Inverters

NC7SP04P5X Description

The NC7SP04P5X is a single-channel inverter IC designed for high-performance logic applications. Manufactured by onsemi, this device is part of the 7SP series and is housed in a compact SC70-5 package, making it ideal for space-constrained designs. The NC7SP04P5X operates over a wide supply voltage range of 0.9V to 3.6V, ensuring compatibility with various power supply configurations. It features a maximum propagation delay of 9.2ns at 3.3V with a load capacitance of 30pF, providing fast signal inversion and minimal delay.

The input logic levels are well-defined, with a low input level ranging from 0.7V to 0.9V and a high input level from 1.6V to 2.1V. This ensures reliable operation across different input signal conditions. The device also offers low quiescent current, with a maximum of 900nA, making it suitable for low-power applications. The output current capability is balanced, with both high and low outputs capable of sourcing and sinking up to 2.6mA.

NC7SP04P5X Features

• Fast Propagation Delay: With a maximum propagation delay of 9.2ns at 3.3V and 30pF, the NC7SP04P5X ensures rapid signal inversion, making it suitable for high-speed digital circuits.
• Wide Supply Voltage Range: The device operates from 0.9V to 3.6V, providing flexibility in power supply requirements and compatibility with various systems.
• Low Quiescent Current: A maximum quiescent current of 900nA minimizes power consumption, making it ideal for battery-powered and low-power applications.
• Balanced Output Current: The NC7SP04P5X can source and sink up to 2.6mA, ensuring robust performance in driving various loads.
• Compact SC70-5 Package: The small form factor allows for integration into compact and densely populated PCB designs.
• Surface Mount Technology: The NC7SP04P5X is designed for surface mount applications, facilitating automated assembly processes and improving reliability.
• Compliance and Standards: The device is REACH unaffected and RoHS3 compliant, ensuring it meets environmental and safety standards for electronics manufacturing.

NC7SP04P5X Applications

The NC7SP04P5X is well-suited for a variety of applications where high-speed signal inversion and low power consumption are critical. Some specific use cases include:

• Digital Signal Processing: Inverting signals in digital circuits, such as clock inversion or data line inversion, to ensure proper signal integrity and timing.
• Consumer Electronics: Used in compact devices like smartphones, tablets, and wearable technology where space and power efficiency are paramount.
• Automotive Electronics: In vehicle control systems and infotainment units, where reliable and fast signal processing is required.
• Industrial Control Systems: Inverting signals in PLCs, sensors, and actuators to ensure accurate and timely control.
• Communication Systems: Inverting signals in communication interfaces, such as UART or SPI, to maintain signal integrity and reduce interference.

Conclusion of NC7SP04P5X

The NC7SP04P5X is a versatile and high-performance inverter IC that offers significant advantages over similar models. Its fast propagation delay, wide supply voltage range, and low quiescent current make it an ideal choice for a wide range of applications. The compact SC70-5 package and surface mount technology ensure it can be easily integrated into modern, space-constrained designs. While the product is currently marked as obsolete, its technical specifications and performance benefits make it a reliable choice for existing designs and legacy systems. For new projects, engineers may consider its features and compatibility with other components in their system architecture.

NC7SP04P5X Documents

Download datasheets and manufacturer documentation for NC7SP04P5X

PCN Assembly/Origin :

FPCN22735X1 Addendum 16/FEB/2022

Datasheets :

NC7SP04L6x Datasheet

PCN Packaging :

Mult Devices 24/Oct/2017       Binary Year Code Marking 15/Jan/2014

PCN Other :

Fab5 Supply Constraint 7/Mar/2022

PCN Obsolescence/ EOL :

Obsolete Notice 15/Dec/2022

PCN Design/Specification :

Standard Marking Lay-out 10/Oct/2022

Environmental Information :

onsemi RoHS       onsemi REACH       Material Declaration NC7SP04P5X
