NC7SZ04L6X-L22175

Gates and Inverters

NC7SZ04L6X-L22175 Description

The NC7SZ04L6X-L22175 is a high-performance inverter IC from ON Semiconductor, designed to meet the demands of modern electronic systems. This 1-channel inverter offers a maximum propagation delay of 4.3ns at 5V and 50pF, making it suitable for high-speed applications. With a supply voltage range of 1.65V to 5.5V, it can be used in a variety of power-sensitive environments.

NC7SZ04L6X-L22175 Features

• Logic Type: Inverter
• Max Propagation Delay: 4.3ns @ 5V, 50pF
• Voltage - Supply: 1.65V ~ 5.5V
• Current - Quiescent (Max): 2 µA
• Current - Output High, Low: 32mA, 32mA
• Number of Inputs: 1
• Number of Circuits: 1
• Mounting Type: Surface Mount
• Package: Tape & Reel (TR)
• RoHS Status: ROHS3 Compliant
• REACH Status: REACH Unaffected
• Moisture Sensitivity Level (MSL): 1 (Unlimited)

The NC7SZ04L6X-L22175 stands out from similar models with its low quiescent current of 2 µA, which helps reduce power consumption in battery-operated devices. Its surface-mount packaging also enables compact and efficient board layouts.

NC7SZ04L6X-L22175 Applications

This inverter IC is ideal for various applications where signal inversion is required, such as:

1. Digital Circuits: Inverting signals in digital logic circuits for data processing and control systems.
2. Automotive Electronics: Signal inversion in automotive control modules for improved performance and reliability.
3. Telecommunications: Inverting signals in communication systems for signal conditioning and amplification.
4. Industrial Control Systems: Inverting sensor signals for monitoring and control in industrial automation.

Conclusion of NC7SZ04L6X-L22175

The NC7SZ04L6X-L22175 is a versatile inverter IC from ON Semiconductor, offering excellent performance and reliability. Its low power consumption, wide supply voltage range, and compact surface-mount packaging make it suitable for a wide range of applications in digital circuits, automotive electronics, telecommunications, and industrial control systems. With its unique features and advantages, the NC7SZ04L6X-L22175 is a valuable addition to any electronic design.
