EXB-F8WT08G

EXB-F8WT08G Description

The EXB-F8WT08G from Panasonic Electronic Components is a high-precision 12-resistor network designed for through-hole mounting applications. Part of the EXB series, this dual terminator network offers 1.5kΩ and 3.3kΩ resistance values with a tight ±2% tolerance and a ±200ppm/°C temperature coefficient, ensuring stable performance across varying environmental conditions. Encased in an 8-pin SIP (Single In-line Package) with dimensions of 0.786" x 0.100" (19.96mm x 2.54mm) and a seated height of 0.195" (4.95mm), this component is optimized for space-constrained PCB designs. Rated at 125mW power per element, it is suitable for low-to-moderate power applications.

EXB-F8WT08G Features

• 12 resistors in a compact 8-pin SIP configuration for efficient circuit integration.
• Dual terminator circuit type enhances signal integrity in termination applications.
• ±2% tolerance and ±200ppm/°C tempco ensure precision and reliability.
• Through-hole mounting provides robust mechanical stability.
• 1.5kΩ and 3.3kΩ resistance options cater to diverse design requirements.
• MSL 1 (Unlimited) rating allows for extended storage without moisture sensitivity concerns.
• Obsolete status may require alternative sourcing for long-term production needs.

EXB-F8WT08G Applications

This resistor network is ideal for:

• Signal termination in communication and data transmission systems.
• Voltage division and impedance matching in analog circuits.
• Industrial control systems requiring stable, high-tolerance resistors.
• Legacy electronics repair where through-hole components are preferred.
• Prototyping and educational projects due to its ease of use and reliable performance.

Conclusion of EXB-F8WT08G

The EXB-F8WT08G is a versatile, precision resistor network offering high tolerance, stable thermal performance, and robust through-hole mounting. While marked as obsolete, its dual terminator design and compact SIP package make it a strong choice for legacy systems, industrial controls, and signal conditioning applications. Engineers should evaluate alternative sourcing or modern equivalents for future-proof designs, but this model remains a reliable solution for specific use cases.
