INN2004K-TL

INN2004K-TL Description

The INN2004K-TL is a high-performance offline switcher IC designed for power management applications, offering a comprehensive solution for efficient power conversion. Manufactured by Power Integrations, this device is part of the INN2004 series and features a flyback topology with secondary side synchronous rectification (SR), ensuring high efficiency and reliability. The INN2004K-TL is packaged in a 16-lead SOIC (Small Outline Integrated Circuit) and is suitable for surface mount applications, making it ideal for compact and high-density designs.

INN2004K-TL Features

• Topology: The INN2004K-TL utilizes a flyback topology with secondary side synchronous rectification, which significantly enhances efficiency and reduces power loss compared to traditional diode rectification methods.
• Voltage Breakdown: With a breakdown voltage of 650V, the INN2004K-TL can handle high voltage inputs, making it suitable for a wide range of applications, including those with wide input voltage ranges.
• Power Output: The device is capable of delivering up to 15 watts of power, making it ideal for applications requiring moderate power levels.
• Switching Frequency: Operating at a switching frequency of 100kHz, the INN2004K-TL ensures efficient power conversion with minimal electromagnetic interference (EMI).
• Fault Protection: Comprehensive fault protection features, including current limiting, over-temperature protection, and over-voltage protection, ensure robust and reliable operation under various operating conditions.
• Internal Switches: The INN2004K-TL includes internal switches, which simplify the design and reduce the number of external components required.
• Compliance and Standards: The device is REACH unaffected and RoHS compliant, ensuring it meets stringent environmental and safety standards.
• Packaging: The INN2004K-TL is available in a tape and reel (TR) package, facilitating automated assembly processes and ensuring high production efficiency.
• Moisture Sensitivity Level: With an MSL of 3 (168 hours), the INN2004K-TL is suitable for use in environments with moderate humidity levels.

INN2004K-TL Applications

The INN2004K-TL is well-suited for a variety of power management applications, particularly those requiring efficient power conversion and high reliability. Key applications include:

• Consumer Electronics: Ideal for power supplies in devices such as televisions, monitors, and other consumer electronics where high efficiency and compact design are crucial.
• Industrial Equipment: Suitable for power management in industrial applications, including control systems, sensors, and other equipment that require reliable power conversion.
• Telecommunications: The INN2004K-TL can be used in power supplies for telecommunications equipment, ensuring efficient power delivery and robust performance.
• Medical Devices: Given its high reliability and compliance with safety standards, the INN2004K-TL is suitable for power management in medical devices where consistent performance and safety are paramount.

Conclusion of INN2004K-TL

The INN2004K-TL offers a robust and efficient solution for power management applications, combining advanced features with high reliability and compliance with industry standards. Its flyback topology with secondary side synchronous rectification ensures high efficiency, while comprehensive fault protection mechanisms guarantee reliable operation. The INN2004K-TL is an excellent choice for designers seeking a compact, high-performance power management IC, particularly in applications requiring moderate power levels and high efficiency.
