M93C86-MN6TP

Memory ICs Products

M93C86-MN6TP Description

The M93C86-MN6TP is a 16Kbit EEPROM memory IC chip manufactured by STMicroelectronics. This chip is designed for surface mount applications and features a Microwire memory interface, providing a compact and efficient solution for embedded systems. The M93C86-MN6TP operates within a supply voltage range of 4.5V to 5.5V and supports a clock frequency of up to 2 MHz. It is organized as 2K x 8 or 1K x 16, offering versatile memory configurations to suit various application requirements. The chip is housed in an 8SOIC package and is available in tape and reel packaging for convenient handling and assembly.

M93C86-MN6TP Features

• Memory Size and Organization: The M93C86-MN6TP offers a 16Kbit EEPROM memory size, organized as 2K x 8 or 1K x 16, providing flexibility in memory allocation and addressing.
• Microwire Interface: This memory interface ensures efficient communication with the host system, making it suitable for applications requiring low pin count and simple interfacing.
• Clock Frequency: With a maximum clock frequency of 2 MHz, the M93C86-MN6TP ensures fast data access and transfer rates, enhancing overall system performance.
• Write Cycle Time: The write cycle time for a word or page is 5ms, ensuring reliable and efficient data storage operations.
• Supply Voltage: The chip operates within a supply voltage range of 4.5V to 5.5V, making it compatible with a wide range of power supply configurations.
• Compliance and Status: The M93C86-MN6TP is REACH unaffected and RoHS3 compliant, adhering to stringent environmental and safety standards. It is also classified under ECCN EAR99 and HTSUS 8542.32.0051.
• Moisture Sensitivity Level: With an MSL of 1 (Unlimited), the chip is highly resistant to moisture, ensuring reliability in various environmental conditions.
• Mounting Type: The surface mount technology (SMT) ensures ease of integration into modern PCB designs, providing robust mechanical and electrical connections.

M93C86-MN6TP Applications

The M93C86-MN6TP is ideal for a wide range of applications that require reliable and efficient non-volatile memory solutions. Some specific use cases include:

• Embedded Systems: The compact size and efficient Microwire interface make it suitable for embedded systems where space and simplicity are critical.
• Industrial Automation: The robustness and reliability of the M93C86-MN6TP ensure it can withstand harsh industrial environments, making it ideal for automation and control systems.
• Telecommunications: The fast data access and storage capabilities of the chip make it suitable for telecommunication applications, such as storing configuration data and firmware.
• Consumer Electronics: The M93C86-MN6TP can be used in consumer electronics for storing user settings, calibration data, and other non-volatile information.

Conclusion of M93C86-MN6TP

The M93C86-MN6TP from STMicroelectronics is a versatile and reliable EEPROM memory IC chip that offers a range of technical specifications and performance benefits. Its Microwire interface, fast clock frequency, and efficient write cycle time make it an excellent choice for applications requiring non-volatile memory solutions. The chip's compliance with industry standards and its robust design ensure it can be integrated into a variety of systems with confidence. Despite its obsolete status, the M93C86-MN6TP remains a valuable component for legacy systems and applications where its unique features and advantages continue to provide reliable performance.
