STMicroelectronics

M93C86-WMN6P

Memory ICs Products

M93C86-WMN6P Description

The M93C86-WMN6P is a high-performance 16Kbit EEPROM memory IC from STMicroelectronics, designed for a wide range of applications in the electronics industry. This EEPROM is based on Microwire technology and offers a unique combination of features, including a 2 MHz clock frequency, 2K x 8 and 1K x 16 memory organization, and a write cycle time of just 5ms. With a supply voltage range of 2.5V to 5.5V, the M93C86-WMN6P is well-suited for various low-power applications.

M93C86-WMN6P Features

• Memory Size and Organization: The M93C86-WMN6P boasts a generous 16Kbit memory capacity, organized as 2K x 8 and 1K x 16. This allows for efficient storage and retrieval of data in various formats, making it ideal for applications requiring large amounts of non-volatile memory.
• Clock Frequency: With a 2 MHz clock frequency, the M93C86-WMN6P offers fast data access and processing capabilities, ensuring high performance in real-time applications.
• Write Cycle Time: The write cycle time of 5ms for words and pages allows for rapid data updates, making the M93C86-WMN6P suitable for applications where frequent data changes are required.
• Voltage Supply Range: The 2.5V to 5.5V supply voltage range makes the M93C86-WMN6P compatible with a wide range of power sources, enhancing its versatility in various electronic systems.
• Package and Mounting Type: The M93C86-WMN6P is available in an 8SOIC package and is surface mountable, making it easy to integrate into PCB designs.
• ECCN and REACH Status: The M93C86-WMN6P is classified as EAR99 and REACH Unaffected, ensuring compliance with international trade and environmental regulations.

M93C86-WMN6P Applications

The M93C86-WMN6P is an ideal choice for a variety of applications where non-volatile memory is required. Some specific use cases include:

• Industrial Control Systems: The M93C86-WMN6P can be used to store configuration settings, calibration data, and firmware updates in industrial control systems, ensuring reliable operation and easy maintenance.
• Automotive Applications: In automotive systems, the M93C86-WMN6P can be used to store vehicle settings, diagnostic data, and entertainment system preferences, providing a customizable user experience.
• Smart Home Devices: The M93C86-WMN6P can be used in smart home devices to store user preferences, device settings, and firmware updates, ensuring seamless integration and operation.

Conclusion of M93C86-WMN6P

The M93C86-WMN6P from STMicroelectronics is a versatile and high-performance EEPROM memory IC that offers a unique combination of features and benefits. Its large memory capacity, fast clock frequency, and low power consumption make it an ideal choice for a wide range of applications in the electronics industry. With its compliance with international trade and environmental regulations, the M93C86-WMN6P is a reliable and eco-friendly solution for your non-volatile memory needs.

M93C86-WMN6P Documents

Download datasheets and manufacturer documentation for M93C86-WMN6P

Datasheets :

M93Cx6-(W,R)

PCN Other :

Packing Bag Chg 03/Sept/2015

HTML Datasheet :

M93Cx6-(W,R)
