SPC584B70E1EDC0X

Microcontrollers

The SPC584B70E1EDC0X is a high-performance, 32-bit microcontroller (MCU) manufactured by STMicroelectronics. It belongs to the ST10 ARM Cortex-M4 family and is designed for automotive and industrial applications that require high performance, safety, and reliability.

Description:

The SPC584B70E1EDC0X is a powerful MCU that features a 32-bit ARM Cortex-M4 core with a maximum clock speed of 150 MHz. It is built on a 130 nm BCD6s process technology, which ensures high performance and low power consumption. The device comes in a compact and robust 100-pin TQFP package, making it suitable for various applications.

Features:

1. Core: 32-bit ARM Cortex-M4 CPU with a maximum clock speed of 150 MHz, providing high processing capabilities.
2. Memory: The MCU offers up to 2 MB of Flash memory and 256 KB of RAM, ensuring ample storage for complex applications.
3. Safety: The SPC584B70E1EDC0X is designed to meet the stringent safety requirements of automotive and industrial applications. It features a Safety Island with error-correcting code (ECC) protection and a fail-safe architecture.
4. Connectivity: The device provides a wide range of communication interfaces, including CAN FD, LIN, Ethernet, USB, and UART, enabling seamless integration with various systems and networks.
5. Timers and PWM: The MCU includes advanced timers and PWM channels, making it suitable for motor control and other time-critical applications.
6. ADC: The SPC584B70E1EDC0X features a high-resolution 12-bit ADC, allowing for accurate analog signal processing.
7. Security: The device includes a range of security features, such as secure boot, flash encryption, and unique chip identifiers, ensuring the protection of sensitive data.
8. Power Management: The MCU offers a flexible power management system, allowing for efficient power consumption in various operating modes.

Applications:

The SPC584B70E1EDC0X is designed for a wide range of applications, particularly in the automotive and industrial sectors, where high performance, safety, and reliability are crucial. Some potential applications include:

1. Motor control: The MCU's advanced timers, PWM channels, and motor control libraries make it well-suited for applications such as electric motor drives, power steering systems, and battery management.
2. Automotive infotainment: The SPC584B70E1EDC0X can be used in infotainment systems, providing high-speed processing and connectivity for multimedia, navigation, and communication features.
3. Industrial automation: The MCU's robust communication interfaces and advanced control capabilities make it suitable for industrial automation systems, such as robotic controllers, machine controllers, and process control systems.
4. Safety systems: The device's safety features and fail-safe architecture make it an ideal choice for applications such as airbag control units, electronic stability control systems, and advanced driver assistance systems (ADAS).
5. Power management: The SPC584B70E1EDC0X can be used in power management applications, such as battery chargers, energy storage systems, and smart grid management.

In summary, the SPC584B70E1EDC0X is a high-performance, 32-bit ARM Cortex-M4 MCU designed for demanding automotive and industrial applications. Its advanced features, such as safety, connectivity, and power management, make it an excellent choice for a wide range of applications requiring high performance, reliability, and safety.

SPC584B70E1EDC0X Documents

Download datasheets and manufacturer documentation for SPC584B70E1EDC0X

Datasheets :

SPC584B70E1

PCN Packaging :

Material Barrier Bag 17/Dec/2020

PCN Design/Specification :

CARRIER TAPE CHANGE 06/APR/2023       Safety Manuals Update 08/Sep/2020
