STMicroelectronics

STM8L152K4U6

Microcontrollers

The STM8L152K4U6 is a low-power microcontroller (MCU) from STMicroelectronics, designed for a wide range of applications that require low energy consumption and high performance. It is based on the STM8 core, which is an 8-bit CPU with a clock speed of up to 16 MHz.

Description:

The STM8L152K4U6 is a member of the STM8L series of ultra-low-power MCUs. It is housed in a 64-pin UFQFPN package, making it suitable for compact and space-constrained applications. The device features a high level of integration, with a range of built-in peripherals and interfaces that can help reduce the overall system cost and complexity.

Features:

1. Core: STM8 8-bit CPU with a clock speed of up to 16 MHz.
2. Memory: 64 Kbytes of Flash memory, 8 Kbytes of RAM, and 1 Kbyte of EEPROM.
3. Power Management: Ultra-low-power modes, including a power-saving mode (PSM) and a standby mode with RAM retention.
4. Communication Interfaces: I2C, SPI, and USART interfaces for communication with external devices.
5. Timers: Multiple timers, including a 16-bit timer with PWM capabilities, a 16-bit timer with dead-time insertion, and an 8-bit timer.
6. ADC: 12-bit ADC with up to 16 channels, suitable for analog signal processing.
7. DAC: 12-bit DAC for generating analog output signals.
8. Security: A range of security features, including a unique 128-bit UID, a hardware encryption engine, and a secure boot option.
9. Connectivity: An RF switch and an RF interface for wireless communication applications.
10. Operating Voltage: 2.4 V to 3.6 V for the core, and 1.8 V to 3.6 V for the I/O.

Applications:

The STM8L152K4U6 is suitable for a wide range of applications that require low power consumption and high performance. Some of the potential applications include:

1. Smart Meters: For energy and utility monitoring.
2. Home Automation: For controlling lighting, heating, and security systems.
3. Wearable Devices: For fitness and health monitoring.
4. Medical Devices: For portable and low-power medical equipment.
5. Industrial Control: For monitoring and controlling industrial processes.
6. Automotive Applications: For power management and control systems in vehicles.
7. Wireless Sensor Networks: For data acquisition and transmission in IoT applications.

In summary, the STM8L152K4U6 is a versatile and low-power microcontroller that can be used in a variety of applications where energy efficiency and performance are critical. Its range of built-in features and interfaces make it a cost-effective and space-saving solution for many embedded systems.

STM8L152K4U6 Documents

Download datasheets and manufacturer documentation for STM8L152K4U6

Datasheets :

STM8L15xx4, xx6 Datasheet

Other Related Documents :

STM8L152K4 View All Specifications

HTML Datasheet :

STM8L15xx4, xx6 Datasheet
