Texas Instruments

DAC161S997RGHT

ADCs/DACs - Special Purpose ICs

DAC161S997RGHT Description

The DAC161S997RGHT from Texas Instruments is a high-precision 16-bit digital-to-analog converter (DAC) designed for applications demanding exceptional accuracy and reliability. Packaged in a compact 16-WQFN form factor, this surface-mount IC operates on a 2.7V to 3.6V dual-supply (analog and digital) and supports multiple serial interfaces, including SPI™, QSPI™, MICROWIRE™, and DSP-compatible protocols. With RoHS3 compliance and REACH unaffected status, it meets stringent environmental and regulatory standards. Its moisture sensitivity level (MSL 3) ensures robustness in industrial environments.

DAC161S997RGHT Features

• 16-bit resolution for ultra-fine analog output control.
• Single-channel output with low noise and high linearity.
• Wide supply voltage range (2.7V–3.6V), suitable for mixed-signal systems.
• Flexible serial interface (SPI/QSPI/MICROWIRE) for seamless DSP/microcontroller integration.
• Tape & Reel (TR) packaging for automated assembly efficiency.
• Industrial-grade reliability with MSL 3 and -40°C to +125°C operating range.
• Low power consumption, ideal for battery-powered or energy-sensitive designs.

DAC161S997RGHT Applications

This DAC excels in precision-critical systems such as:

• Industrial automation: Calibration, process control, and sensor signal conditioning.
• Test & measurement equipment: High-resolution waveform generation and calibration.
• Medical devices: Patient monitoring and diagnostic instrumentation.
• Communications infrastructure: Base station power control and RF tuning.
• Automotive electronics: Advanced driver-assistance systems (ADAS) and infotainment.

Conclusion of DAC161S997RGHT

The DAC161S997RGHT combines 16-bit precision, versatile interfacing, and industrial durability, making it a standout choice for high-performance analog systems. Its low-power operation and compact footprint cater to space-constrained designs, while compliance with RoHS3 and REACH ensures global usability. Engineers seeking a reliable, high-resolution DAC for industrial, medical, or automotive applications will find this IC an optimal solution.

DAC161S997RGHT Documents

Download datasheets and manufacturer documentation for DAC161S997RGHT

PCN Assembly/Origin :

Alt Base Metal 31/Jul/2020

Datasheets :

DAC161S997

HTML Datasheet :

DAC161S997
