DCP010515DBP-U

External/Internal DC DC Converters

DCP010515DBP-U Description

The DCP010515DBP-U from Texas Instruments is a high-efficiency, dual-output isolated DC-DC converter designed for industrial and commercial applications. Part of the DCP01B (1W) series, it delivers ±15V outputs with a combined maximum current of 33mA per channel, providing 1W total power in a compact surface-mount package. With an input voltage range of 4.5V to 5.5V, it ensures stable performance in low-voltage systems. The module features 1 kV isolation, making it suitable for noise-sensitive or safety-critical designs. Its 85% efficiency minimizes power loss, while compliance with ROHS3 and REACH ensures environmental safety.

DCP010515DBP-U Features

• Dual Outputs: Provides ±15V for applications requiring bipolar supplies.
• High Isolation: 1 kV isolation protects sensitive circuits from ground loops and noise.
• Compact Design: Measures just 19.7mm × 8.3mm × 5.3mm, ideal for space-constrained PCBs.
• Protection Features: Includes Over-Temperature Protection (OTP) and Short-Circuit Protection (SCP) for enhanced reliability.
• Control Interface: Enable pin (Active High) allows for power management.
• Wide Input Range: Operates from 4.5V to 5.5V, compatible with standard 5V logic supplies.
• High Efficiency: 85% efficiency reduces thermal stress and improves energy utilization.

DCP010515DBP-U Applications

• Industrial Automation: Powers isolated sensors, PLCs, and control systems.
• Medical Devices: Suitable for low-power diagnostic equipment requiring noise immunity.
• Test & Measurement: Provides stable bipolar supplies for precision instrumentation.
• Telecom & Networking: Used in isolated signal conditioning and data acquisition.
• Commercial ITE: Ideal for embedded systems, IoT devices, and low-power peripherals.

Conclusion of DCP010515DBP-U

The DCP010515DBP-U stands out for its compact size, dual-output capability, and robust isolation, making it a versatile solution for applications demanding reliable power conversion. Its high efficiency, protection features, and compliance with environmental standards ensure long-term performance in demanding environments. Whether in industrial, medical, or commercial systems, this module offers a dependable and space-efficient power solution.
