Texas Instruments

LP5912-2.8DRVR

Linear & Switching Voltage Regulators

LP5912-2.8DRVR Description

The LP5912-2.8DRVR is a linear voltage regulator from Texas Instruments, designed for applications requiring a stable 2.8V output with a maximum current of 500mA. This device is part of the Linear & Switching Voltage Regulators category and is currently active in the market. With a fixed output type, it offers a reliable and efficient power solution for various electronic systems.

LP5912-2.8DRVR Features

• Output Type: Fixed
• Voltage - Input (Max): 6.5V
• Current - Output: 500mA
• Number of Regulators: 1
• Output Configuration: Positive
• Current - Supply (Max): 600 µA
• Product Status: Active
• REACH Status: REACH Unaffected
• Manufacturer: Texas Instruments
• Voltage - Output (Min/Fixed): 2.8V
• Voltage Dropout (Max): 0.25V @ 500mA
• RoHS Status: ROHS3 Compliant
• Moisture Sensitivity Level (MSL): 1 (Unlimited)
• Current - Quiescent (Iq): 55 µA
• PSRR: 80dB ~ 40dB (100Hz ~ 100kHz)
• ECCN: EAR99
• Mounting Type: Surface Mount
• Control Features: Enable, Power Good, Soft Start
• Protection Features: Over Temperature, Reverse Polarity, Short Circuit
• HTSUS: 8542.39.0001
• Package: Tape & Reel (TR)
• Base Product Number: LP5912

LP5912-2.8DRVR Applications

The LP5912-2.8DRVR is ideal for applications where a stable and efficient power supply is crucial. Some specific use cases include:

1. Portable Electronic Devices: Due to its low quiescent current and small form factor, it is suitable for powering portable electronics such as smartphones, tablets, and wearable devices.
2. Industrial Equipment: Its robust protection features make it suitable for industrial applications where reliability and stability are essential.
3. Automotive Systems: The device's ability to handle reverse polarity and short circuit protection makes it ideal for automotive electronics, ensuring safety and performance in harsh environments.

Conclusion of LP5912-2.8DRVR

The LP5912-2.8DRVR from Texas Instruments is a versatile and reliable linear voltage regulator, offering a fixed 2.8V output with a maximum current of 500mA. Its unique features, such as low quiescent current, robust protection features, and compliance with RoHS3, make it an excellent choice for a wide range of applications, from portable electronics to industrial and automotive systems. With its fixed output and positive configuration, the LP5912-2.8DRVR provides a stable and efficient power solution for demanding applications.

LP5912-2.8DRVR Documents

Download datasheets and manufacturer documentation for LP5912-2.8DRVR

PCN Assembly/Origin :

Wafer Fab Site 08/May/2023

Datasheets :

LP5912 Datasheet

HTML Datasheet :

LP5912 Datasheet
