PTN78060AAH

External/Internal DC DC Converters

The PTN78060AAH is a high-performance, automotive-qualified, synchronous step-down regulator from Texas Instruments. It is designed to provide efficient power conversion in various automotive applications, such as infotainment systems, instrument clusters, and advanced driver-assistance systems (ADAS).

Description:

The PTN78060AAH is a highly integrated, synchronous step-down regulator that offers a wide input voltage range of 4.5V to 40V. It can deliver an output voltage as low as 0.1V and supports an output current of up to 6A. The device is available in a compact, thermally-optimized, 24-pin HTSSOP package.

Features:

1. Wide input voltage range: 4.5V to 40V
2. Low output voltage: down to 0.1V
3. High output current: up to 6A
4. Synchronous rectification for improved efficiency
5. Automotive-qualified: AEC-Q100 qualified, suitable for automotive applications
6. Programmable soft-start and track features
7. Over-current protection, over-voltage protection, and thermal shutdown protection
8. Low quiescent current: 3.5µA in normal operation
9. High accuracy and stability over temperature and line variations
10. Spread-spectrum frequency modulation to reduce electromagnetic interference (EMI)

Applications:

1. Automotive infotainment systems
2. Instrument clusters
3. Advanced driver-assistance systems (ADAS)
4. Body control modules
5. Power modules for various automotive electronic systems
6. General-purpose step-down conversion in industrial and commercial applications

The PTN78060AAH is an ideal choice for automotive applications requiring a highly efficient, reliable, and compact step-down regulator. Its automotive qualification, wide input voltage range, and low output voltage capability make it suitable for a variety of power conversion needs in the automotive industry.
