REF3120AIDBZT

Voltage References

REF3120AIDBZT Description

The REF3120AIDBZT is a high-performance, low-noise voltage reference from Texas Instruments, designed to deliver precise and stable voltage outputs for a variety of electronic applications. This device features a fixed output voltage of 2.048V with an impressive tolerance of ±0.2%, ensuring high accuracy and reliability in voltage reference applications. The REF3120AIDBZT is housed in a compact SOT23-3 package, making it ideal for space-constrained designs while maintaining robust performance.

REF3120AIDBZT Features

• Fixed Output Voltage: The REF3120AIDBZT provides a stable output voltage of 2.048V, ideal for precision applications requiring a consistent reference voltage.
• Low Tolerance: With a tolerance of ±0.2%, this voltage reference ensures high accuracy, making it suitable for applications where precision is critical.
• Low Noise: The device exhibits a low noise level of 39µVrms over the 10Hz to 10kHz frequency range, minimizing the impact of noise on sensitive analog circuits.
• Low Temperature Coefficient: A temperature coefficient of 20ppm/°C ensures minimal drift over varying temperatures, maintaining accuracy across a wide operating range.
• Low Supply Current: Consuming only 135µA of supply current, the REF3120AIDBZT is highly efficient and suitable for low-power applications.
• Wide Input Voltage Range: The device operates over an input voltage range of 2.098V to 5.5V, providing flexibility in power supply requirements.
• Surface Mount Packaging: The SOT23-3 package is ideal for surface mount applications, offering a compact footprint and ease of integration into modern PCB designs.
• Compliance and Reliability: The REF3102AIDBZT is REACH unaffected, RoHS3 compliant, and has an ECCN classification of EAR99, ensuring compliance with environmental and regulatory standards.

REF3120AIDBZT Applications

The REF3120AIDBZT is well-suited for a range of applications where precision voltage references are required. These include:

• Analog-to-Digital Converters (ADCs): Provides a stable reference voltage to ensure accurate conversion of analog signals to digital data.
• Digital-to-Analog Converters (DACs): Ensures precise output voltage levels for high-fidelity signal generation.
• Precision Measurement Equipment: Used in devices requiring high accuracy and low noise, such as oscilloscopes and multimeters.
• Power Management Systems: Offers a reliable reference voltage for voltage regulation and monitoring circuits.
• Medical Devices: Suitable for applications precision where and reliability are paramount, such as medical instrumentation and diagnostic equipment.

Conclusion of REF3120AIDBZT

The REF3120AIDBZT from Texas Instruments stands out as a high-performance voltage reference, offering a combination of precision, low noise, and low power consumption. Its compact SOT23-3 package and wide input voltage range make it a versatile solution for a variety of electronic applications. With its low temperature coefficient and accuracy high, the REF3120AIDBZT ensures reliable performance across different operating conditions. Whether used in precision measurement equipment, ADCs, DACs, or power management systems, the REF3120AIDBZT delivers the stability and reliability needed for demanding applications.
