SN65LVDS324ZQLR

Specialized Backplane Connectors

The SN65LVDS324ZQLR is a high-speed, 3.3V, 4-channel LVDS transmitter from Texas Instruments. This device is designed to transmit high-speed serial data over long distances with low power consumption and high signal integrity.

Description:

The SN65LVDS324ZQLR is a 4-channel LVDS transmitter that operates at 3.3V and supports data rates up to 622 Mbps per channel. It uses a differential signaling scheme to transmit data over long distances with minimal signal degradation. The device is available in a 20-pin QFN package.

Features:

1. 4 channels of LVDS transmission
2. Supports data rates up to 622 Mbps per channel
3. 3.3V operation
4. Low power consumption
5. Differential signaling for improved signal integrity
6. Integrated output drivers for easy interfacing with LVDS receivers
7. Wide operating temperature range (-40°C to +85°C)
8. RoHS compliant

Applications:

The SN65LVDS324ZQLR is ideal for a variety of high-speed data transmission applications, including:

1. Video transmission in industrial and automotive applications
2. Data communication in telecommunications and networking equipment
3. Medical imaging and diagnostic equipment
4. High-speed data acquisition and signal processing systems
5. Audio and video distribution in professional audio/video systems
6. Digital signage and display systems
7. Security and surveillance systems

In summary, the SN65LVDS324ZQLR is a versatile and high-performance LVDS transmitter that offers excellent signal integrity and low power consumption, making it suitable for a wide range of high-speed data transmission applications.
