SN74LVT16244BGQLR

SN74LVT16244BGQLR Description

The SN74LVT16244BGQLR is a high-performance, non-inverting buffer Logic IC Chip designed by Texas Instruments. This device is part of the 74LVT series and features a 56-BGA package, making it ideal for surface mount applications. It operates within a supply voltage range of 2.7V to 3.6V and is capable of handling up to 32mA of output current in the high state and 64mA in the low state. The SN74LVT16244BGQLR is organized into four elements, each with four bits, providing robust and reliable signal buffering and conditioning.

SN74LVT16244BGQLR Features

• High Current Capability: With output currents of 32mA (high) and 64mA (low), the SN74LVT16244BGQLR ensures robust performance in demanding applications.
• Wide Operating Voltage Range: The device operates within a supply voltage range of 2.7V to 3.6V, making it versatile for various power supply configurations.
• Surface Mount Compatibility: The 56-BGA package is designed for surface mount technology, facilitating efficient integration into modern electronic systems.
• ECCN Classification: Classified under ECCN EAR99, this device is suitable for a broad range of applications without export restrictions.
• Compliance Standards: The SN74LVT16244BGQLR meets REACH and RoHS3 compliance standards, ensuring environmental and safety regulations are met.
• Moisture Sensitivity Level: With an MSL of 1 (unlimited), the device is highly resistant to moisture, enhancing its reliability in various environmental conditions.

SN74LVT16244BGQLR Applications

The SN74LVT16244BGQLR is ideal for applications requiring high-performance signal buffering and conditioning. Its high current capability and wide operating voltage range make it suitable for:

• High-Speed Data Transmission: Ideal for buffering signals in high-speed data communication systems.
• Digital Signal Processing: Provides reliable signal conditioning in digital signal processing applications.
• Industrial Control Systems: Enhances the performance of industrial control systems by ensuring robust signal integrity.
• Consumer Electronics: Suitable for consumer electronics where high current and reliable signal buffering are required.

Conclusion of SN74LVT16244BGQLR

The SN74LVT16244BGQLR from Texas Instruments is a versatile and high-performance non-inverting buffer Logic IC Chip. Its wide operating voltage range, high current capability, and surface mount compatibility make it an excellent choice for a variety of applications. Compliance with REACH and RoHS3 standards ensures that it meets environmental and safety regulations. While the product is now obsolete, it remains a reliable option for existing designs and legacy systems. For new projects, designers may consider exploring alternative models from Texas Instruments' extensive portfolio of Logic IC Chips.
