Texas Instruments

TCAN1044DRBRQ1

Drivers, Receivers, Transceivers

The TCAN1044DRBRQ1 is a high-speed CAN (Controller Area Network) transceiver manufactured by Texas Instruments. It is designed to provide reliable communication in automotive and industrial applications that require high-speed data transmission.

Description:

The TCAN1044DRBRQ1 is a single-chip CAN transceiver that operates at data rates up to 1 Mbps. It features a 3.3V supply voltage and a wide operating temperature range of -40°C to +125°C. The device is available in a compact QFN package, making it suitable for space-constrained applications.

Features:

1. High-speed data transmission: Supports data rates up to 1 Mbps, making it suitable for applications requiring high-speed communication.
2. Wide operating temperature range: Operates reliably in temperatures ranging from -40°C to +125°C, making it suitable for harsh environments.
3. 3.3V supply voltage: Compatible with low-voltage systems, reducing power consumption and heat generation.
4. Enhanced fault tolerance: The device features protection against short circuits, overvoltage, and other fault conditions, ensuring reliable operation.
5. Standby mode: The TCAN1044DRBRQ1 can be placed in a low-power standby mode to conserve energy when not in use.
6. Sleep mode: A sleep mode is also available for even lower power consumption during periods of inactivity.
7. SPI interface: The device can be configured and monitored using a standard SPI interface, simplifying integration with microcontrollers and other control systems.

Applications:

The TCAN1044DRBRQ1 is suitable for a wide range of applications that require high-speed, reliable communication, including:

1. Automotive networks: Used for in-vehicle communication between various electronic control units (ECUs) and sensors.
2. Industrial control systems: Facilitates communication between different components in manufacturing and automation systems.
3. Medical equipment: Enables high-speed data transmission between medical devices and monitoring systems.
4. Robotics: Supports communication between robot controllers and various sensors and actuators.
5. Aerospace: Used for communication in aircraft and aerospace systems, where reliability and performance are critical.

In summary, the TCAN1044DRBRQ1 is a high-speed, reliable CAN transceiver from Texas Instruments, designed for use in automotive, industrial, medical, and aerospace applications. Its features, such as a wide operating temperature range, low-voltage operation, and enhanced fault tolerance, make it an ideal choice for demanding communication requirements.

TCAN1044DRBRQ1 Documents

Download datasheets and manufacturer documentation for TCAN1044DRBRQ1

PCN Assembly/Origin :

Mult Dev Wafer Fab Site 22/Dec/2023

Datasheets :

TCAN1044V-Q1
