Texas Instruments

TCAN1044DRQ1

Drivers, Receivers, Transceivers

The TCAN1044DRQ1 is a high-speed CAN (Controller Area Network) transceiver from Texas Instruments. It is designed to provide reliable communication in automotive and industrial applications that require high-speed data transmission and low electromagnetic interference (EMI).

Description:

The TCAN1044DRQ1 is a single-chip solution that integrates a CAN protocol controller and a physical layer transceiver. It operates at data rates up to 1 Mbps and supports both standard and extended CAN identifiers. The device is available in a compact QFN package, making it suitable for space-constrained applications.

Features:

1. High-speed operation up to 1 Mbps.
2. Support for both standard (11-bit) and extended (29-bit) CAN identifiers.
3. Integrated CAN protocol controller and physical layer transceiver.
4. Low electromagnetic interference (EMI) design.
5. Robust error handling capabilities, including bit rate monitoring, error counter, and error logging.
6. Support for sleep mode to reduce power consumption in low-power applications.
7. Wide operating temperature range (-40°C to +125°C).
8. Available in a compact QFN package.

Applications:

1. Automotive applications, such as in-vehicle networks, engine control, and safety systems.
2. Industrial automation and control systems, including robotic control, machine-to-machine communication, and sensor networks.
3. Medical equipment, where reliable and high-speed data communication is crucial.
4. Aerospace and defense applications, where robust communication and low EMI are essential.
5. IoT devices and smart home systems, where multiple devices need to communicate with each other.

The TCAN1044DRQ1 is a versatile and reliable CAN transceiver that can be used in a wide range of applications requiring high-speed data transmission and low EMI. Its compact form factor and robust error handling capabilities make it an ideal choice for both automotive and industrial applications.

TCAN1044DRQ1 Documents

Download datasheets and manufacturer documentation for TCAN1044DRQ1

PCN Assembly/Origin :

Mult Dev Wafer Fab Site 22/Dec/2023

Datasheets :

TCAN1044V-Q1

PCN Design/Specification :

Design 25/Feb/2022
