Texas Instruments

TMS320F2808PZA

Microcontrollers

The Texas Instruments TMS320F2808PZA is a high-performance microcontroller belonging to the TMS320F28Mx series. It is designed for real-time control and digital signal processing applications. Here's a brief description, features, and applications of the TMS320F2808PZA:

Description:

The TMS320F2808PZA is a 32-bit fixed-point microcontroller featuring the TMS320F2808 CPU. It is built on a 150 MHz CPU with a 16-bit instruction set, providing high computational efficiency and real-time performance. The device comes in a 100-pin PQFP package.

Features:

1. CPU: 32-bit TMS320F2808 CPU with a 150 MHz clock speed.
2. Memory: 256 KB on-chip program memory (16-bit wide), 40 KB on-chip data memory (16-bit wide), and up to 512 KB of external memory.
3. Event Manager: A flexible event manager for peripheral control and data transfer.
4. Communication interfaces: Two CAN (Controller Area Network) modules, one SCI (Serial Communication Interface), and one SPI (Serial Peripheral Interface).
5. Analog-to-Digital Converters (ADCs): 12-bit, 200 ksps ADC with up to 16 input channels.
6. Digital-to-Analog Converters (DACs): 12-bit DAC with one output channel.
7. PWM: Advanced high-resolution PWM with up to 6 channels.
8. External Memory Interface: Supports external memory types like SRAM, SDRAM, and external memory mapping.
9. Security: Secure boot, secure memory, and secure communication features.
10. Power management: Low-power modes to optimize energy consumption.
11. Protection: Overvoltage, undervoltage, and thermal protection.

Applications:

The TMS320F2808PZA is suitable for a wide range of applications that require real-time control, digital signal processing, and communication capabilities. Some of the key applications include:

1. Industrial control: Motor control, robotics, and automation systems.
2. Power electronics: Power converters, solar inverters, and energy storage systems.
3. Automotive: Engine control, transmission control, and safety systems.
4. Renewable energy: Wind turbine control, photovoltaic power systems, and energy management.
5. Medical equipment: Medical imaging, patient monitoring, and portable medical devices.
6. Communication systems: Data acquisition, voice over IP (VoIP), and network routers.
7. Consumer electronics: Home appliances, audio/video processing, and smart devices.

The TMS320F2808PZA's combination of high computational power, real-time performance, and advanced communication interfaces make it a versatile choice for various embedded systems and control applications.

TMS320F2808PZA Documents

Download datasheets and manufacturer documentation for TMS320F2808PZA

Errata :

TMS320F2809/8/6/2/1(X),TMS320C2802/1 Errata

PCN Assembly/Origin :

AIZU 26/Aug/2016

Datasheets :

TMS320F2809PZS Datasheet

PCN Packaging :

New Tray 08/Jun/2020       14x14x1.4 LQFP Tray Update 26/Sep/2013

Getting Started Guide :

TMS320C28x Getting Started

PCN Design/Specification :

TMS320x 26/Aug/2019
