Texas Instruments

TPS56C230RJER

DC Switching Voltage Regulators

TPS56C230RJER is a highly integrated, step-down (buck) switching regulator from Texas Instruments. It is designed to provide efficient and stable power conversion for a wide range of applications. Here's a brief description, features, and applications of the TPS56C230RJER:

Description:

The TPS56C230RJER is a synchronous, step-down switching regulator that can accept a wide input voltage range of 4.5V to 22V and provide a regulated output voltage as low as 0.9V. It is available in a compact, 20-pin, 3mm x 4mm RoHS-compliant, leadless, thermally enhanced overmolded package.

Features:

1. Wide input voltage range: 4.5V to 22V
2. Output voltage as low as 0.9V
3. High efficiency up to 95%
4. Synchronous rectification for improved efficiency
5. Integrated high and low side MOSFETs
6. Programmable soft-start
7. Internal compensation for easy external component selection
8. Over-current protection (OCP)
9. Over-voltage protection (OVP)
10. Thermal shutdown protection
11. Small form factor: 20-pin, 3mm x 4mm package

Applications:

1. Portable devices: smartphones, tablets, and wearables
2. Power banks and battery chargers
3. Industrial and automotive applications
4. LED lighting and drivers
5. Telecommunication equipment
6. Medical devices
7. Consumer electronics

The TPS56C230RJER is a versatile and efficient switching regulator that can be used in a wide range of applications requiring step-down power conversion. Its compact size, high efficiency, and integrated features make it an ideal choice for space-constrained and power-sensitive designs.

TPS56C230RJER Documents

Download datasheets and manufacturer documentation for TPS56C230RJER

PCN Assembly/Origin :

TLV/TPS 16/Mar/2022

Datasheets :

TPS56C230

HTML Datasheet :

TPS56C230

PCN Design/Specification :

Assembly Materials 28/Dec/2021
