Texas Instruments

TXS0102DCTR

Translators, Level Shifters

The TXS0102DCTR is a dual bidirectional voltage level translator from Texas Instruments. It is designed to translate the voltage levels of digital signals between two different voltage domains, allowing for communication between systems operating at different voltage levels.

Description:

The TXS0102DCTR is a 2-channel, bidirectional level translator that operates from a 1.2V to 3.6V supply voltage. It features a small package size of 6mm x 6mm and is available in a 16-pin QFN package. The device is designed to translate the voltage levels of digital signals between two different voltage domains, allowing for communication between systems operating at different voltage levels.

Features:

• 2-channel bidirectional level translation
• Operating voltage range of 1.2V to 3.6V
• I/O voltage range of 1.2V to 3.6V
• Small package size of 6mm x 6mm
• Available in a 16-pin QFN package

Applications:

The TXS0102DCTR is commonly used in a variety of applications where communication between systems operating at different voltage levels is required. Some common applications include:

• Automotive infotainment systems
• Industrial control systems
• Medical equipment
• Consumer electronics
• Communication systems
• Computer peripherals
  Overall, the TXS0102DCTR is a versatile and reliable level translator that can help ensure smooth communication between systems operating at different voltage levels.

TXS0102DCTR Documents

Download datasheets and manufacturer documentation for TXS0102DCTR

PCN Assembly/Origin :

Assembly Site 29/Mar/2023

Datasheets :

TXS0102

HTML Datasheet :

TXS0102

PCN Design/Specification :

TXS0102DCyy Assembly/Design 07/Dec/2023       TXS0102DCxR 29/Nov/2023
