Vishay

MDP14031K60GE04

MDP14031K60GE04 Description

The MDP14031K60GE04 from Vishay is a high-performance thick film resistor network designed for precision applications requiring stable resistance values and robust thermal performance. This 14-pin DIP (Dual In-line Package) device integrates 7 isolated resistors, each with a 1.6KΩ resistance and a tight 2% tolerance, ensuring consistent performance in demanding circuits. With a power rating of 1.73W (0.25W per resistor) and a wide operating temperature range of -55°C to +125°C, it excels in environments where thermal stability is critical. The molded package enhances durability, while the ±100ppm/°C temperature coefficient guarantees minimal resistance drift over temperature variations.

MDP14031K60GE04 Features

• Isolated Resistor Network: 7 independent thick film resistors in a single DIP package, ideal for isolation-critical designs.
• High Power Handling: 1.73W total power dissipation (0.25W per resistor) with derating up to 150°C.
• Precision Tolerance: 2% tolerance and ±100ppm/°C TCR ensure accuracy across temperature fluctuations.
• Robust Construction: Molded rectangular DIP package (19.05mm x 7.87mm x 3.05mm) with through-hole pin termination for reliable mounting.
• Compliance: EU RoHS compliant (with exemption) and EAR99 ECCN, suitable for global markets.
• Automotive-Grade Alternatives: While not automotive-qualified, its 125°C max operating temperature makes it suitable for industrial and telecom applications.

MDP14031K60GE04 Applications

• Industrial Control Systems: Precision voltage dividers, signal conditioning, and feedback networks in PLCs and motor drives.
• Telecommunications: Isolation resistors in line drivers, modems, and RF modules requiring stable impedance.
• Test & Measurement Equipment: Calibration circuits and reference networks where low drift is essential.
• Power Supplies: Current sensing and balancing in multi-channel DC/DC converters.
• Medical Electronics: Patient monitoring systems demanding high reliability and isolation.

Conclusion of MDP14031K60GE04

The MDP14031K60GE04 stands out for its isolated resistor design, high power density, and exceptional thermal stability, making it a superior choice for precision analog and mixed-signal circuits. Its molded DIP package ensures mechanical robustness, while the thick film technology delivers long-term reliability. Engineers will appreciate its balance of performance and compactness, particularly in industrial, telecom, and instrumentation applications where resistance accuracy and power handling are paramount. For designs requiring repeatable performance under thermal stress, this resistor network is a dependable solution.
