A: The W25Q128FVSIG delivers high performance and low power consumption. Its key specifications are summarised in the table below: Specification Value Memory Density 128 Mbit (16 Mbyte) Memory Organization 16M × 8 bits (65,536 pages of 256 bytes each) Max Clock Frequency 104 MHz Equivalent Quad I/O Data Rate 416 MHz (104 MHz × 4) Page Program Time (Tpp) 0.7 ms (max) Sector Erase (4KB) 45 ms (typ) / 400 ms (max) Block Erase (32KB) 120 ms (max) Block Erase (64KB) 150 ms (max) Supply Voltage (VCC) 2.7 V to 3.6 V Active Read Current 4 mA (typical) Standby (Power‑down) Current 1 μA (typical) Endurance 100,000 program/erase cycles (minimum) Data Retention 20 years (minimum) Operating Temperature –40 °C to +85 °C (industrial grade) Package 8‑pin SOIC (208 mil / 5.30 mm width) RoHS Status RoHS compliant / Lead‑Free Additional features include 4 KB uniform sectors for flexible parameter storage, hardware and software write protection, a 64‑bit unique serial number, three 256‑byte security registers with OTP locks, a HOLD pin for pausing ongoing serial communication, and programmable output driver strength.

A: The device communicates over a standard 4‑wire SPI bus and supports three flexible SPI modes, plus QPI mode: Standard SPI (Single I/O): Uses separate DI (data in) and DO (data out) pins for 1‑bit transfers. Compatible with virtually all SPI controllers. Dual SPI (Dual I/O): Uses IO0 and IO1 pins as bidirectional I/O, transferring 2 bits of data per clock cycle, effectively doubling the data rate. Quad SPI (Quad I/O): Uses all four I/O pins (IO0, IO1, IO2, IO3) for simultaneous transfer of 4 bits per clock cycle, achieving equivalent data rates of up to 416 MHz (104 MHz × 4). QPI (Quad Peripheral Interface): A 2‑clock instruction cycle mode that further reduces command overhead and improves throughput. The Continuous Read Mode allows efficient memory access with as few as 8 clocks of instruction overhead to read a 24‑bit address, enabling true Execute‑In‑Place (XIP) operation where the host executes code directly from the flash without copying to RAM first.

A: The W25Q128FVSIG is engineered for long‑term reliability. Key reliability specifications include: Reliability Parameter Specification Program/Erase Endurance 100,000 cycles per sector (minimum) Data Retention 20 years (minimum) Page Program Time (Tpp) 0.7 ms (max) for 256‑byte page Sector Erase Time (4KB) 400 ms (max) Block Erase Time (32KB/64KB) 120 ms / 150 ms (max) Operating Temperature –40 °C to +85 °C (industrial grade) Deep Power‑Down Current 1 μA (typical) The device’s 100,000 program/erase cycles and 20‑year data retention meet industry‑standard requirements for NOR Flash technology. It also features hardware and software write protection with programmable write protection (CMP, SEC, TB, BP[2:0] bits) and Individual Block Locks, write enable latch (WEL), and a 64‑bit Unique Serial Number for device traceability, making it suitable for applications that require occasional firmware updates, secure boot storage, and long‑term code retention.

A: The W25Q128FVSIG is a versatile 128M‑bit Serial NOR Flash memory widely used in embedded systems requiring reliable code and data storage. Typical applications include: Firmware storage and Bootloader – Boot code, system firmware and BIOS in embedded systems, supporting IAP (In‑Application Programming) and OTA (Over‑The‑Air) upgrades. Execute‑In‑Place (XIP) – Direct code execution from Quad SPI without copying to RAM, reducing system memory requirements. Consumer electronics – Smart TVs, set‑top boxes, digital cameras, smart speakers and gaming consoles for firmware and resource storage. Industrial control – PLCs, HMIs, data loggers and industrial automation equipment for storing control programs, parameters and historical data. IoT and smart devices – Wi‑Fi modules, Bluetooth modules, smart home controllers and sensor nodes for device firmware, network configuration and OTA upgrade caching. Automotive electronics – In‑vehicle infotainment, T‑Box telematics terminals, OBD diagnostic devices and navigation systems for firmware and map data caching. Wearable devices – Smartwatches, fitness trackers and smart glasses for UI icons, font libraries and voice command storage. ⚠️ Important Lifecycle Information: The product lifecycle status for the W25Q128FVSIG is contradictory across distributor databases. Major distributors explicitly list the part as “停产” (Discontinued) and “Obsolete” (Lifecycle: Obsolete), with some describing the status as “Discontinued at Digi-Key”. However, other sources indicate that the device is “in stock” and “available for purchase” with immediate delivery. The discrepancy likely reflects that while the manufacturer may have phased out active production, remaining stock still exists in the distribution channel. For new designs requiring long‑term supply assurance, Winbond recommends the newer W25Q128JV series (W25Q128JVSIQ, W25Q128JVPIM, etc.) as the direct drop‑in replacement with enhanced specifications and active production status. Given the conflicting lifecycle reports, engineers are strongly advised to verify current lifecycle status, availability and lead times directly with an authorised Winbond distributor (such as Digi‑Key, Mouser, Farnell or Arrow) before committing this part to a new high‑volume design. For legacy systems already using the W25Q128FVSIG, remaining inventory may still be available, but for new projects requiring long‑term supply assurance, migrating to the W25Q128JV series is strongly recommended.
