Bourns, Inc.

CAY16-223J4AS

Resistor Networks & Arrays

CAY16-223J4AS Description

The CAY16-223J4AS from Bourns Inc. is a 4-resistor network in a compact 1206 (3216 Metric) package with convex, long-side terminals. Designed for surface-mount applications, it features isolated resistors with a 22kΩ resistance per element and a ±5% tolerance, ensuring reliable performance in precision circuits. With a ±200ppm/°C temperature coefficient, this array maintains stable operation across varying thermal conditions. The device offers 63mW power dissipation per element and is RoHS3 compliant, meeting modern environmental standards. Its 1206 footprint (3.20mm x 1.60mm) and low-profile 0.60mm height make it ideal for space-constrained designs.

CAY16-223J4AS Features

• 4 isolated resistors in a single 1206 package, reducing board space and assembly complexity.
• 22kΩ resistance with ±5% tolerance, suitable for signal conditioning and voltage division.
• Low thermal drift (±200ppm/°C) ensures stability in temperature-sensitive applications.
• 63mW power rating per resistor, balancing performance and thermal management.
• RoHS3 compliant and MSL 1 (Unlimited), suitable for lead-free processes and extended shelf life.
• Convex, long-side terminals enhance solder joint reliability in automated assembly.

CAY16-223J4AS Applications

This resistor network excels in analog and digital circuits requiring matched resistance values, such as:

• Voltage dividers in sensor interfaces and ADC circuits.
• Pull-up/pull-down networks in microcontroller and FPGA designs.
• Signal termination for high-speed data lines (e.g., SPI, I²C).
• Industrial and automotive electronics, where stable resistance under thermal stress is critical.
• Consumer electronics, including wearables and IoT devices, benefiting from its compact size.

Conclusion of CAY16-223J4AS

The CAY16-223J4AS combines high-density integration, stable performance, and robust construction, making it a versatile choice for modern electronics. While marked Obsolete, its design remains relevant for legacy systems or replacements. Engineers value its space-saving 1206 package, consistent tolerance, and thermal resilience, particularly in applications demanding precision and reliability. For designs requiring matched resistors with minimal footprint, this Bourns array delivers a proven solution.

CAY16-223J4AS Documents

Download datasheets and manufacturer documentation for CAY16-223J4AS

Datasheets :

CAY16-AS Series Datasheet

PCN Obsolescence/ EOL :

Mult Series 06/Jul/2021
