FDPC8014S

FET, MOSFET Arrays

FDPC8014S Description

The FDPC8014S is a high-performance MOSFET (Metal Oxide) from onsemi, designed for power applications. It features a PowerTrench® series structure, offering superior performance in terms of switching speed and power dissipation. The device is designed to operate in a wide range of applications, including motor control, power supplies, and industrial control systems. With a maximum drain-source voltage (Vdss) of 25V and a continuous drain current (Id) of up to 20A/41A at 25°C, the FDPC8014S is capable of handling high power levels efficiently.

FDPC8014S Features

• Logic Level Gate: The FDPC8014S is designed to work with logic level gate inputs, making it compatible with a wide range of control systems.
• Low Input Capacitance: With a maximum input capacitance (Ciss) of 2375pF at 13V, the device offers fast switching speeds and reduced power consumption.
• Low Gate Charge: A maximum gate charge (Qg) of 35nC at 10V ensures efficient power usage and fast switching.
• Low Rds On: The maximum Rds On of 3.8mOhm at 20A and 10V contributes to low conduction losses and high efficiency.
• High Vgs(th): A maximum Vgs(th) of 2.5V at 250µA ensures reliable switching and easy integration with existing control systems.
• Surface Mount: The device is available in a Surface Mount package, making it suitable for high-density PCB designs.
• Power Clip 56 Package: The FDPC8014S comes in a Power Clip 56 package, providing a compact and robust solution for power applications.

FDPC8014S Applications

The FDPC8014S is ideal for a variety of high-power applications, including:

1. Motor Control: The device's high current handling capability and low Rds On make it suitable for motor control applications, where high efficiency and fast switching are required.
2. Power Supplies: The FDPC8014S can be used in power supply designs, where high voltage and current ratings are necessary.
3. Industrial Control Systems: The device's robustness and high power handling capability make it suitable for use in industrial control systems, where reliability and performance are critical.

Conclusion of FDPC8014S

The FDPC8014S is a high-performance MOSFET from onsemi, offering a combination of high power handling, fast switching, and low power consumption. Its unique features, such as logic level gate operation, low input capacitance, and low Rds On, make it an ideal choice for a wide range of power applications. However, it is important to note that the product is currently marked as obsolete, which may limit its availability. Despite this, the FDPC8014S remains a strong contender in the market for high-power MOSFET solutions.
