NCP1063AP060G

AC DC Converters, Offline Switches

NCP1063AP060G Description

The NCP1063AP060G from onsemi is a high-performance offline switcher IC designed for AC/DC converter applications. This active, ROHS3-compliant device integrates a 700V breakdown voltage MOSFET switch, supporting buck and flyback topologies with a 100kHz switching frequency. It operates within a 7V to 20V supply range, featuring a low 9V startup voltage for efficient power-up. With a 15.5W power rating and 66% duty cycle, it delivers reliable performance in compact designs. The IC is packaged in a 7DIP through-hole format, making it suitable for industrial and consumer applications requiring robust offline power conversion.

NCP1063AP060G Features

• Integrated 700V MOSFET: Eliminates the need for an external switch, reducing BOM cost and board space.
• Wide Vcc Range (7V–20V): Ensures stable operation under varying input conditions.
• Advanced Protection: Includes overload, over-power, over-temperature, and short-circuit fault protection for enhanced reliability.
• Flexible Topologies: Supports buck and flyback configurations, ideal for diverse power supply designs.
• Low Startup Voltage (9V): Enables quick and efficient system initialization.
• 100kHz Switching Frequency: Balances efficiency and EMI performance.
• REACH Unaffected & MSL Not Applicable: Suitable for environmentally conscious and high-reliability applications.

NCP1063AP060G Applications

• Auxiliary Power Supplies: For industrial control systems and appliances.
• LED Drivers: Efficient power management for lighting solutions.
• Consumer Electronics: Adapters, set-top boxes, and small offline converters.
• Isolated/Non-Isolated Designs: Due to its either-output isolation capability.
• Battery Chargers: Compact and reliable power delivery for low-to-medium power charging systems.

Conclusion of NCP1063AP060G

The NCP1063AP060G stands out as a versatile, high-efficiency offline switcher IC, combining integration, protection, and flexibility. Its 700V MOSFET, robust fault protection, and multi-topology support make it ideal for cost-sensitive yet demanding applications. Whether used in consumer electronics, industrial systems, or LED drivers, this IC ensures reliable performance, simplified design, and compliance with environmental standards. A top choice for engineers seeking a balance of power, efficiency, and compactness in offline power conversion.
