Texas Instruments

TPS54336ADRCR

DC Switching Voltage Regulators

The TPS54336ADRCR is a high-efficiency synchronous step-down (buck) regulator from Texas Instruments. It is designed to provide a stable output voltage from a wide range of input voltages. Here is a brief description of the device along with its features and applications:

Description:

The TPS54336ADRCR is a highly integrated, high-efficiency synchronous step-down regulator that can operate from an input voltage range of 4.75V to 23V. It is available in a compact 10-lead DFN (3x3mm) package. The device features a wide output voltage range of 0.9V to 5.5V and can deliver a continuous output current of up to 3A.

Features:

1. High Efficiency: The TPS54336ADRCR offers high efficiency of up to 95%, which helps in reducing power dissipation and improving overall system performance.
2. Wide Input Voltage Range: The device can operate from an input voltage range of 4.75V to 23V, making it suitable for a wide range of applications.
3. Wide Output Voltage Range: The output voltage range of the device is from 0.9V to 5.5V, which allows it to be used in various applications with different voltage requirements.
4. High Output Current: The device can deliver a continuous output current of up to 3A, making it suitable for applications that require high current.
5. Synchronous Rectification: The device uses synchronous rectification, which helps in improving efficiency and reducing power dissipation.
6. Low Dropout Voltage: The TPS54336ADRCR has a low dropout voltage, which allows it to maintain high efficiency even at low input voltages.
7. Protection Features: The device includes various protection features such as over-current protection, over-temperature protection, and output short-circuit protection.

Applications:

The TPS54336ADRCR is suitable for a wide range of applications that require a stable and efficient power supply. Some of the key applications include:

1. Portable Electronics: The device can be used in portable electronics such as smartphones, tablets, and wearable devices to provide a stable power supply.
2. Industrial Equipment: The TPS54336ADRCR can be used in industrial equipment that requires a stable and efficient power supply, such as motor controllers and sensor interfaces.
3. Automotive Applications: The device can be used in automotive applications such as infotainment systems, instrument clusters, and lighting systems.
4. Medical Devices: The TPS54336ADRCR can be used in medical devices that require a stable and efficient power supply, such as portable medical instruments and wearable medical devices.
5. Telecommunication Equipment: The device can be used in telecommunication equipment such as routers, switches, and base stations to provide a stable power supply.

In summary, the TPS54336ADRCR is a highly efficient synchronous step-down regulator from Texas Instruments that offers a wide input voltage range, high output current, and various protection features. It is suitable for a wide range of applications that require a stable and efficient power supply.

TPS54336ADRCR Documents

Download datasheets and manufacturer documentation for TPS54336ADRCR

Datasheets :

TPS54335A, TPS54336A Datasheet

Design Resources :

TPS54336A Design with WEBENCH® Power Designer

HTML Datasheet :

TPS54335A, TPS54336A Datasheet

PCN Design/Specification :

Mult Dev Material Chg 29/Mar/2018
