HMC784AMS8GETR

RF Switches

HMC784AMS8GETR Description

The HMC784AMS8GETR is a high-performance SPDT (Single Pole Double Throw) reflective RF switch from Analog Devices Inc., designed for WiMAX/WiBro applications. Operating at a 5V supply voltage, this surface-mount switch delivers exceptional linearity with a typical IIP3 of 60dBm and a P1dB of 41dBm, ensuring robust signal handling in high-power RF environments. Packaged in an 8MSOP format and supplied in Tape & Reel (TR), it is optimized for automated assembly. With a 50Ω impedance and a frequency range up to 4GHz, this switch is ideal for demanding RF systems requiring low insertion loss and high isolation.

HMC784AMS8GETR Features

• High Linearity: 60dBm IIP3 and 41dBm P1dB for superior signal integrity in high-power applications.
• Reflective Topology: Minimizes insertion loss and enhances isolation, critical for WiMAX/WiBro systems.
• Robust Construction: ROHS3 Compliant and REACH Unaffected, meeting stringent environmental standards.
• Moisture-Resistant: MSL 1 (Unlimited) rating ensures reliability in humid conditions.
• Compact Form Factor: 8MSOP package saves board space while maintaining high RF performance.

HMC784AMS8GETR Applications

• WiMAX/WiBro Base Stations: High linearity and power handling make it ideal for RF front-end switching.
• Test & Measurement Equipment: Precision switching for signal routing in lab and field instruments.
• Military/Aerospace Systems: Reliable performance in harsh environments due to robust construction.
• 5G Infrastructure: Supports high-frequency switching needs in next-gen networks.

Conclusion of HMC784AMS8GETR

The HMC784AMS8GETR stands out as a high-linearity, high-power RF switch with exceptional performance in WiMAX/WiBro and broadband applications. Its reflective topology, compact packaging, and compliance with environmental standards make it a superior choice for engineers designing advanced RF systems. Whether for commercial wireless infrastructure or mission-critical military applications, this switch delivers reliability, efficiency, and precision.
