IC MCU 8BIT 256KB FLASH 100TQFP
In Stock : Please Inquiry

Not available to buy online? Want the lower wholesale price? Please Send RFQ to get best price, we will respond immediately

QUICK RFQ
ADD TO RFQ LIST
ersa FreeSample
ISO9001
Quality Policy
ISO45001
ISO14001

ATMEGA2560-16AU Description

The ATMEGA2560-16AU is a microcontroller unit (MCU) manufactured by Microchip Technology. It is a part of the AVR Enhanced series of MCUs, which are known for their high performance, low power consumption, and advanced features.

Description:

The ATMEGA2560-16AU is a high-density, 8-bit microcontroller with a high level of integration. It features 256KB of In-System Programmable Flash memory, 16KB of SRAM, and 4KB of EEPROM. The MCU operates at a frequency of up to 16 MHz and has a wide operating voltage range of 1.8-5.5V.

Features:

  1. High-performance 8-bit AVR core with 16 x 16-bit Multiply-Accumulate (MAC) instruction
  2. 256KB In-System Programmable Flash memory with read-while-write capability
  3. 16KB SRAM and 4KB EEPROM
  4. 54 general-purpose I/O lines with optional internal pull-up resistors
  5. 2 UARTs with programmable baud rates, separate RX/TX lines, and optional modem control lines
  6. 2 8-bit Timer/Counters with PWM channels, 2 16-bit Timer/Counters with PWM channels, and 8-bit Timer/Counter with asynchronous mode
  7. 2 8-bit PWM channels with independent clock source
  8. 16-bit, 2-channel USB interface with on-chip PHY and internal USB oscillator
  9. 16-bit, 4-channel ADC with up to 10 external single-ended inputs or 5 differential inputs
  10. 2 digital comparators with internal reference voltage
  11. 2-channel DMA controller
  12. On-chip debug system with JTAG interface
  13. Brownout detection with programmable threshold and hysteresis
  14. Power-save mode, power-down mode, and standby mode for low-power operation
  15. Operating temperature range of -40°C to +85°C

Applications:

The ATMEGA2560-16AU is suitable for a wide range of applications due to its high performance, low power consumption, and advanced features. Some potential applications include:

  1. Industrial control systems
  2. Robotics and automation
  3. Motor control applications
  4. Portable and battery-powered devices
  5. Medical equipment
  6. Telecommunication systems
  7. Networking and internet of things (IoT) devices
  8. Consumer electronics
  9. Automotive systems
  10. Security systems

The ATMEGA2560-16AU's versatility and advanced features make it a popular choice for developers working on complex embedded systems that require high performance, low power consumption, and a wide range of communication interfaces.
