Micron Technology

MT25QL256ABA1EW9-0SIT

Name: MT25QL256ABA1EW9-0SIT
Brand: Micron Technology
SKU: 774-MT25QL256ABA1EW9-0SIT
Price: 7.00628 USD
Availability: InStock

Manufacturer:

Micron Technology

ERSA Part #:

774-MT25QL256ABA1EW9-0SIT

Datasheet:

PDF Datasheet

Description:

IC FLASH 256MBIT SPI 8WPDFN

Standard Lead Time:

17 weeks

RoHS Status:

Why Choose Us?

Professional Platform

B2B & B2C purchasing

Delivery at full speed

1-2 days delivery

Wide variety

Original manufacturers

365 days guarantee

Responsible quality

Tech Specifications

Clock Frequency

133 MHz

Unit Weight

0.091428 oz

Program Current (mA)

Part Status Code

Production

Number of Components

PPAP

Automotive

RoHS

RoHS Compliant

MT25QL256ABA1EW9-0SIT Description

Micron Technology | 3V Serial NOR Flash

MT25QL256ABA1EW9-0SIT

256Mb (32MB) 3V Quad SPI NOR Flash | 133MHz | Execute-in-Place (XIP) | Industrial Temperature

✔️ Industrial Temp: -40°C to +85°C ⚡ 133MHz / 90MB/s Quad Read

BRAND

Micron

MT25QL Series

256Mb
Density (32MB)

2.7-3.6V
Supply Range

133MHz
Clock Frequency

90MB/s
Quad Throughput

WPDFN-8
6x8mm Package

Product Overview

The Micron MT25QL256ABA1EW9-0SIT is a 256Mb (32,768K x 8) high-performance serial NOR Flash memory from the MT25Q family[reference:0][reference:1][reference:2]. Operating from a standard 2.7V to 3.6V power supply[reference:3][reference:4][reference:5][reference:6], it supports standard SPI, Dual SPI, and Quad SPI modes, with a maximum clock frequency of 133 MHz in Quad I/O mode[reference:7][reference:8][reference:9][reference:10][reference:11], delivering a read throughput of up to 90 MB/s[reference:12][reference:13][reference:14]. This makes it ideal for execute‑in‑place (XIP), fast booting, and code storage in industrial, networking, and embedded systems[reference:15][reference:16][reference:17][reference:18].

The device is organized as 32,768 programmable pages of 256 bytes each, with a flexible erase architecture: 4KB sectors, 32KB/64KB blocks, and full chip erase[reference:19][reference:20]. Housed in a compact 8‑pad WPDFN (6x8mm) package[reference:21][reference:22][reference:23][reference:24][reference:25], it operates over the industrial temperature range of -40°C to +85°C[reference:26][reference:27][reference:28][reference:29]. With 100,000 program/erase cycles and 20‑year data retention[reference:30][reference:31][reference:32], the MT25QL256ABA delivers the endurance and reliability required for industrial control, communications, medical devices, and automotive aftermarket applications[reference:33].

📊 Technical Specifications

Density / Organization	256Mb (32M x 8) — 32MB[reference:34][reference:35][reference:36]
Memory Interface	SPI / Dual SPI / Quad SPI[reference:37][reference:38]
Max Clock Frequency	133 MHz (Quad I/O)[reference:39][reference:40][reference:41][reference:42]
Quad Read Throughput	Up to 90 MB/s[reference:43][reference:44][reference:45]
Page Program Size	256 bytes per page
Erase Granularity	4KB sector, 32KB/64KB block, full chip erase[reference:46][reference:47]
Supply Voltage (Vcc)	2.7V – 3.6V[reference:48][reference:49][reference:50][reference:51]
Operating Temperature	Industrial: -40°C to +85°C[reference:52][reference:53][reference:54][reference:55]
Storage Temperature	-65°C to +150°C
Package Type	8‑pad WPDFN (6x8mm) — 1EW9 code[reference:56][reference:57][reference:58][reference:59][reference:60]
Package Dimensions	6.0 x 8.0 x 0.75 mm[reference:61]
Endurance	100,000 program/erase cycles[reference:62][reference:63][reference:64]
Data Retention	20 years @ 55°C[reference:65][reference:66][reference:67]
Write Cycle Time (Page)	2.8ms[reference:68][reference:69][reference:70]
Active Read Current	35 mA (max)[reference:71]
Write Protection	Hardware WP# pin, software block protection[reference:72]
Security Features	Unique 64‑bit ID, OTP security register
Suspend/Resume	Supported for program/erase operations[reference:73][reference:74]
RoHS / Halogen Free	Yes — RoHS3 compliant[reference:75][reference:76]
Moisture Sensitivity Level	MSL 3 (168 hours)[reference:77][reference:78][reference:79]
Part Status	Active — In production[reference:80][reference:81]

✨ Key Features

✅ High‑Speed Quad SPI – 133MHz clock, up to 90 MB/s throughput for fast XIP and boot[reference:82][reference:83][reference:84]
✅ Industry Standard 3V Operation – 2.7‑3.6V wide range, compatible with most SoCs[reference:85][reference:86][reference:87]
✅ Low Power Consumption – Optimized for battery‑powered and portable devices[reference:88][reference:89]
✅ 256Mb High Density – 32MB for code, data logging, and OTA updates[reference:90][reference:91][reference:92]
✅ Execute‑in‑Place (XIP) Support – Direct code execution from Flash memory[reference:93][reference:94][reference:95][reference:96]
✅ Flexible Erase Architecture – 4KB sectors, 32KB/64KB blocks, plus chip erase[reference:97][reference:98]
✅ Hardware & Software Write Protection – WP# pin and configurable protected area[reference:99]
✅ Unique 64‑bit ID & OTP Register – factory‑programmed unique ID for device authentication
✅ Suspend/Resume Capability – allows interruption of erase/program for latency‑sensitive reads[reference:100][reference:101]
✅ High Reliability – 100K P/E cycles, 20‑year data retention at 55°C[reference:102][reference:103][reference:104]
✅ Industrial Temperature Range – -40°C to +85°C for harsh environments[reference:105][reference:106][reference:107]
✅ Compact WPDFN-8 Package – 6x8mm footprint, ideal for space‑constrained designs[reference:108][reference:109][reference:110]
✅ JEDEC Standard Command Set – interoperable with most SPI NOR Flash controllers
✅ Long‑term Availability – Micron’s commitment to industrial and embedded markets (15+ years)

🎯 Target Applications:

Industrial control systems, networking routers/switches, set‑top boxes, smart home hubs, IoT gateways, medical devices, automotive aftermarket infotainment, FPGA configuration storage, and battery‑powered portable devices[reference:111].

⚡ Quad SPI Performance & Modes

Standard SPI (1-1-1)

Single I/O: 133 Mbps
Compatible with all SPI hosts

Dual SPI (1-1-2)

2‑bit read: 266 Mbps
Good speed / pin trade‑off

Quad SPI (1-4-4)

4‑bit read: Up to 90 MB/s (720 Mbps)[reference:112][reference:113]
Optimal XIP performance

The MT25QL256ABA supports QPI (Quad Peripheral Interface) mode where all commands and addresses are transmitted over 4 I/O lines. It also features Single and Double Transfer Rate (STR/DTR) modes[reference:114][reference:115], providing flexibility for high‑speed random access and enabling seamless execute‑in‑place (XIP) without code shadowing to RAM[reference:116][reference:117].

🔒 Security & Write Protection Features

🔑 Unique 64‑bit Device ID
Each MT25QL256ABA is factory‑programmed with a unique serial number, enabling device authentication, anti‑counterfeiting, and simple inventory tracking.

📦 OTP (One‑Time Programmable) Register
A dedicated OTP area for permanent storage of encryption keys, serial numbers, or manufacturing data. The OTP region can be locked permanently to prevent further writes.

🛡️ Flexible Write Protection
The Block Protection bits allow software‑defined protection of up to 50% of the memory[reference:118]. When the hardware WP# pin is driven low, the status register becomes read‑only, preventing any modification to the protection scheme[reference:119].

⏸️ Program/Erase Suspend
During a long erase operation (up to 400ms for 64KB block), the host can issue a suspend command, perform a read from another sector, and then resume the erase without data corruption[reference:120][reference:121].

📦 Ordering Information & Part Number Decoder

Orderable Part Number	Temperature	Package	Description
MT25QL256ABA1EW9-0SIT	-40°C to +85°C	WPDFN-8 (6x8mm)	Industrial, tray (1920 pcs/tray)[reference:122]
MT25QL256ABA1EW9-0SIT TR	-40°C to +85°C	WPDFN-8 (6x8mm)	Tape & Reel[reference:123]
MT25QL256ABA8ESF-0SIT	-40°C to +85°C	SOIC-16 (300mil)	Industrial, SOIC package
MT25QL256ABA8E12-0SIT	-40°C to +85°C	TBGA-24	Industrial, BGA package
MT25QL256ABA1EW9-0AAT	-40°C to +105°C	WPDFN-8 (6x8mm)	Automotive Grade (AEC-Q100)

🔍 Part Number Breakdown (MT25QL256ABA1EW9-0SIT):
• MT25Q – Micron Quad SPI NOR Flash family
• L – 3V (L) vs U for 1.8V
• 256 – 256Mb density
• ABA – Configuration / die revision
• 1E – Package: WPDFN (6x8mm)[reference:124]
• W9 – Industrial temperature (-40°C to +85°C) and green
• 0SIT – Tape & Reel (0), SIT = industrial temperature, lead‑free

🏆 Micron Technology – Leader in NOR Flash

Micron Technology is a global leader in memory and storage solutions, with over 40 years of innovation. The MT25Q family represents Micron’s high‑performance NOR Flash portfolio, widely used in industrial, automotive, and consumer electronics. Micron’s NOR Flash products are known for excellent endurance, data retention, and long‑term supply continuity.

Top 3 NOR Flash supplier worldwide – trusted by major OEMs
AEC‑Q100 qualified automotive grade options available
ISO 9001, ISO 14001, IATF 16949 certified fabs
Advanced NOR process nodes for high density and low power
Long‑term product commitment – 15‑20 year availability for industrial and automotive

🌟 Why Choose MT25QL256ABA1EW9-0SIT?

• Industry‑standard 133MHz Quad read – up to 90 MB/s[reference:125][reference:126]

• Low power consumption for battery‑powered devices[reference:127]

• 32MB density in compact 6x8mm WPDFN package[reference:128]

• Industrial temperature -40°C to +85°C[reference:129]

• Backed by Micron’s quality and long‑term supply

🛠️ Development Tools & Support

📄 Datasheet & App Notes

Full specification, AC/DC characteristics, timing diagrams, and hardware design guidelines[reference:130][reference:131].

💻 Software Drivers

Example C code for SPI read/write, Quad mode initialization, and protection management (available on Micron GitHub).

🔌 Programmer Support

Compatible with all major programmers: Elnec, Xeltek, DediProg, Segger J‑Link (SPI mode).

Micron provides free samples, evaluation boards, and direct FAE support through authorized distributors. Design‑in assistance, IBIS models, and failure analysis are available for qualified customers.

📄 Certifications & Compliance

RoHS 2011/65/EU (Compliant)[reference:132][reference:133]
REACH SVHC (Compliant)[reference:134][reference:135]
Halogen‑free per IEC 61249-2-21
Conflict Minerals (CFSI) report available
ECCN: 3A991B1A[reference:136]
JEDEC JESD47H‑compliant[reference:137][reference:138]

📦 Packaging & Logistics

Tray: 1920 pieces per tray[reference:139]
Tape & Reel: available upon request
Moisture Sensitivity Level: MSL 3[reference:140][reference:141][reference:142]
Lead finish: NiPdAu (green, lead‑free)
Lead time: 8‑10 weeks ARO, stock via distributors

📧 [email protected] | 🌐 www.micron.com/products/nor-flash/mt25q

FAQ

This device is a 256 Megabit (256Mb / 32MB) serial NOR Flash memory. It is organized as 32M × 8 bits or 64M × 4 bits. It is a non-volatile memory device that retains data even when power is removed.
